LNK603DG-TL
Power Integrations
Tape & Reel (TR) Cut Tape (CT)-40°C ~ 150°C (TJ)Up to 85kHz
Ref. price$0.9100
Lead time on requestGet quote ›
Power Integrations LNK6 Series
32 variants · Power Integrations
About the Power Integrations Power Integrations LNK6 Series series
The Power Integrations Power Integrations LNK6 Series series groups 32 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. Every variant in the range shares a common control features of -, fault protection of Current Limiting, Open Loop, Over Temperature, Short Circuit and internal switch of Yes. Variants differ by case, duty cycle and frequency, so you can match the exact case your application requires using the selection guide below. All listed Power Integrations LNK6 Series part numbers are active and orderable.
Select a variant by
- Case
- 8-DIP (0.300\", 7.62mm), 7 Leads · 8-SMD (7 Leads), Gull Wing · 8-SOIC (0.154\", 3.90mm Width), 7 Leads
- Duty cycle
- 54% · 55%
- Frequency
- 100kHz · Up to 85kHz
- Mounting type
- Surface Mount · Through Hole
- Operating temperature
- -40°C ~ 150°C (TJ) · -40°C~150°C(TJ)
- Package
- Tape & Reel (TR) Cut Tape (CT) · Tape & Reel (TR); Cut Tape (CT) · Tube
- Power (Watts)
- 3.3 W · 4.1 W · 5.1 W · 6.1 W · 9 W
Variant comparison
| Parameter | LNK603DG-TL | LNK603PG | LNK604DG-TL | LNK605DG-TL | LNK605PG | LNK606DG-TL |
|---|---|---|---|---|---|---|
| Case | 8-SOIC (0.154\", 3.90mm Width), 7 Leads | 8-DIP (0.300\", 7.62mm), 7 Leads | 8-SOIC (0.154\", 3.90mm Width), 7 Leads | 8-SOIC (0.154\", 3.90mm Width), 7 Leads | 8-DIP (0.300\", 7.62mm), 7 Leads | 8-SOIC (0.154\", 3.90mm Width), 7 Leads |
| Duty cycle | 55% | 55% | 55% | 55% | 55% | 55% |
| Frequency | Up to 85kHz | Up to 85kHz | Up to 85kHz | Up to 85kHz | Up to 85kHz | Up to 85kHz |
| Mounting type | Surface Mount | Through Hole | Surface Mount | Surface Mount | Through Hole | Surface Mount |
| Operating temperature | -40°C ~ 150°C (TJ) | -40°C~150°C(TJ) | -40°C~150°C(TJ) | -40°C~150°C(TJ) | -40°C~150°C(TJ) | -40°C~150°C(TJ) |
| Package | Tape & Reel (TR) Cut Tape (CT) | Tube | Tape & Reel (TR); Cut Tape (CT) | Tape & Reel (TR); Cut Tape (CT) | Tube | Tape & Reel (TR); Cut Tape (CT) |
| Power (Watts) | 3.3 W | 3.3 W | 4.1 W | 5.1 W | 5.1 W | 6.1 W |
Shared specifications
- Control features
- -
- Fault protection
- Current Limiting, Open Loop, Over Temperature, Short Circuit
- Internal switch
- Yes
- Output isolation
- Isolated
- Topology
- Flyback
- Voltage - supply (Vcc (Vdd))
- -
Request a quote on any Power Integrations LNK6 Series part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.
Frequently asked questions
- How do the Power Integrations Power Integrations LNK6 Series variants differ?
- Power Integrations LNK6 Series part numbers differ by case, duty cycle, frequency and mounting type. Use the selection guide above to pick by case.
- How many Power Integrations Power Integrations LNK6 Series part numbers are listed?
- 32 Power Integrations Power Integrations LNK6 Series part numbers are listed, each with specifications and a datasheet where available.
- How do I get pricing and lead time for Power Integrations Power Integrations LNK6 Series?
- Request a quote (RFQ) for any Power Integrations LNK6 Series part number and we confirm price, availability and lead time per line — including end-of-life and hard-to-find variants.
