How do the onsemi onsemi 2N70 Series variants differ?

onsemi 2N70 Series part numbers differ by case, current - continuous drain (Id) @ 25°C, drive voltage (Max rds on, min rds on) and input capacitance (Ciss) (Max) @ vds. Use the selection guide above to pick by case.

How many onsemi onsemi 2N70 Series part numbers are listed?

12 onsemi onsemi 2N70 Series part numbers are listed, each with specifications and a datasheet where available.

onsemi 2N70 Series

12 variants · onsemi

About the onsemi onsemi 2N70 Series series

The onsemi onsemi 2N70 Series series groups 12 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. Every variant in the range shares a common drain to source voltage of 60 V, FET feature of - and FET type of N-Channel. Variants differ by case, current - continuous drain (Id) @ 25°C and drive voltage (Max rds on, min rds on), so you can match the exact case your application requires using the selection guide below. The range mixes active and legacy part numbers, so you can source both current onsemi 2N70 Series variants and discontinued ones from a single page.

Select a variant by

Case: SC-70, SOT-323 · SC-89, SOT-490 · TO-226-3, TO-92-3 (TO-226AA) · TO-226-3, TO-92-3 (TO-226AA) Formed Leads · TO-236-3, SC-59, SOT-23-3
Current - continuous drain (Id) @ 25°C: 115mA (Ta) · 115mA (Tc) · 200mA (Ta) · 200mA (Tc) · 260mA (Ta) · 310mA (Ta) · 320mA (Ta) · 350mA (Tc)
Drive voltage (Max rds on, min rds on): 4.5V, 10V · 5V, 10V
Input capacitance (Ciss) (Max) @ vds: 24.5 pF @ 20 V · 40 pF @ 25 V · 43 pF @ 25 V · 50 pF @ 25 V
Mounting type: Surface Mount · Through Hole
Operating temperature: -55°C ~ 150°C (TJ) · -55°C~150°C(TJ) · 150°C (TJ)
Package: Bulk · Cut Tape (CT) Tape & Box (TB) · Tape & Reel (TR) Cut Tape (CT) · Tape & Reel (TR); Cut Tape (CT)
Power dissipation: 1W (Tc) · 200mW (Ta) · 225mW (Ta) · 280mW (Tj) · 300mW (Ta) · 300mW (Tj) · 350mW (Ta) · 350mW (Tc) · 400mW (Ta)

Variant comparison

Parameter	2N7000	2N7002	2N7000-D26Z	2N7000-D74Z	2N7000-D75Z	2N7002ET7G
Case	TO-226-3, TO-92-3 (TO-226AA)	TO-236-3, SC-59, SOT-23-3	TO-226-3, TO-92-3 (TO-226AA) Formed Leads	TO-226-3, TO-92-3 (TO-226AA) Formed Leads	TO-226-3, TO-92-3 (TO-226AA) Formed Leads	TO-236-3, SC-59, SOT-23-3
Current - continuous drain (Id) @ 25°C	350mA (Tc)	200mA (Tc)	200mA (Ta)	200mA (Ta)	200mA (Ta)	260mA (Ta)
Drive voltage (Max rds on, min rds on)	4.5V, 10V	4.5V, 10V	4.5V, 10V	4.5V, 10V	4.5V, 10V	4.5V, 10V
Input capacitance (Ciss) (Max) @ vds	43 pF @ 25 V	43 pF @ 25 V	50 pF @ 25 V	50 pF @ 25 V	50 pF @ 25 V	40 pF @ 25 V
Mounting type	Through Hole	Surface Mount	Through Hole	Through Hole	Through Hole	Surface Mount
Operating temperature	-55°C ~ 150°C (TJ)	-55°C~150°C(TJ)	-55°C ~ 150°C (TJ)	-55°C ~ 150°C (TJ)	-55°C ~ 150°C (TJ)	-55°C ~ 150°C (TJ)
Package	Bulk	Tape & Reel (TR); Cut Tape (CT)	Tape & Reel (TR) Cut Tape (CT)	Cut Tape (CT) Tape & Box (TB)	Cut Tape (CT) Tape & Box (TB)	Tape & Reel (TR) Cut Tape (CT)
Power dissipation	1W (Tc)	350mW (Tc)	400mW (Ta)	400mW (Ta)	400mW (Ta)	300mW (Tj)

Shared specifications

Drain to source voltage: 60 V
FET feature: -
FET type: N-Channel
Technology: MOSFET (Metal Oxide)

Request a quote on any onsemi 2N70 Series part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.

Frequently asked questions

How do the onsemi onsemi 2N70 Series variants differ?: onsemi 2N70 Series part numbers differ by case, current - continuous drain (Id) @ 25°C, drive voltage (Max rds on, min rds on) and input capacitance (Ciss) (Max) @ vds. Use the selection guide above to pick by case.
How many onsemi onsemi 2N70 Series part numbers are listed?: 12 onsemi onsemi 2N70 Series part numbers are listed, each with specifications and a datasheet where available.
How do I get pricing and lead time for onsemi onsemi 2N70 Series?: Request a quote (RFQ) for any onsemi 2N70 Series part number and we confirm price, availability and lead time per line — including end-of-life and hard-to-find variants.
