MK22DN512VLK5
NXP USA Inc.
Tray-40°C ~ 105°C (TA)50MHz
Ref. price$12.3900
Lead time on requestGet quote ›
NXP Semiconductors MK22 Series
6 variants · NXP Semiconductors
About the NXP Semiconductors NXP Semiconductors MK22 Series series
The NXP Semiconductors NXP Semiconductors MK22 Series series groups 6 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. Every variant in the range shares a common core processor of ARM® Cortex®-M4, core size of 32-Bit Single-Core and mounting type of Surface Mount. Variants differ by case, connectivity and data converters, so you can match the exact case your application requires using the selection guide below. All listed NXP Semiconductors MK22 Series part numbers are active and orderable.
Select a variant by
- Case
- 64-LQFP · 80-LQFP · 80-UFBGA, WLCSP · 100-LQFP · 121-XFBGA
- Connectivity
- CANbus, EBI/EMI, I²C, IrDA, SPI, UART/USART, USB, USB OTG · CANbus, EBI/EMI, I²C, LINbus, SPI, UART/USART, USB, USB OTG · I2C, IrDA, SPI, UART/USART, USB, USB OTG · I²C, IrDA, SPI, UART/USART, USB, USB OTG
- Data converters
- A/D 2x16b; D/A 2x12b · A/D 20x16b; D/A 1x12b · A/D 22x16b; D/A 2x12b · A/D 27x16b; D/A 1x12b · A/D 33x16b; D/A 1x12b · A/D 34x16b; D/A 1x12b
- Number of i (O)
- 40 · 52 · 56 · 66 · 67
- Operating temperature
- -40°C ~ 85°C (TA) · -40°C ~ 105°C (TA)
- Package
- Tape & Reel (TR) · Tape & Reel (TR) Cut Tape (CT) · Tray
- Peripherals
- DMA, I2S, LVD, POR, PWM, WDT · DMA, I²S, LVD, POR, PWM, WDT
- Program memory size
- 1MB (1M x 8) · 128KB (128K x 8) · 512KB (512K x 8)
Variant comparison
| Parameter | MK22DN512VLK5 | MK22FN128VDC10 | MK22FN512CAP12R | MK22FN512VLH12R | MK22FN1M0AVLK12 | MK22FN1M0AVLL12 |
|---|---|---|---|---|---|---|
| Case | 80-LQFP | 121-XFBGA | 80-UFBGA, WLCSP | 64-LQFP | 80-LQFP | 100-LQFP |
| Connectivity | I²C, IrDA, SPI, UART/USART, USB, USB OTG | I²C, IrDA, SPI, UART/USART, USB, USB OTG | I2C, IrDA, SPI, UART/USART, USB, USB OTG | I²C, IrDA, SPI, UART/USART, USB, USB OTG | CANbus, EBI/EMI, I²C, LINbus, SPI, UART/USART, USB, USB OTG | CANbus, EBI/EMI, I²C, IrDA, SPI, UART/USART, USB, USB OTG |
| Data converters | A/D 20x16b; D/A 1x12b | A/D 34x16b; D/A 1x12b | A/D 2x16b; D/A 2x12b | A/D 22x16b; D/A 2x12b | A/D 27x16b; D/A 1x12b | A/D 33x16b; D/A 1x12b |
| Number of i (O) | 56 | 67 | 52 | 40 | 56 | 66 |
| Operating temperature | -40°C ~ 105°C (TA) | -40°C ~ 105°C (TA) | -40°C ~ 85°C (TA) | -40°C ~ 105°C (TA) | -40°C ~ 105°C (TA) | -40°C ~ 105°C (TA) |
| Package | Tray | Tray | Tape & Reel (TR) Cut Tape (CT) | Tape & Reel (TR) | Tray | Tray |
| Peripherals | DMA, I²S, LVD, POR, PWM, WDT | DMA, I²S, LVD, POR, PWM, WDT | DMA, I2S, LVD, POR, PWM, WDT | DMA, I²S, LVD, POR, PWM, WDT | DMA, I²S, LVD, POR, PWM, WDT | DMA, I²S, LVD, POR, PWM, WDT |
| Program memory size | 512KB (512K x 8) | 128KB (128K x 8) | 512KB (512K x 8) | 512KB (512K x 8) | 1MB (1M x 8) | 1MB (1M x 8) |
Shared specifications
- Core processor
- ARM® Cortex®-M4
- Core size
- 32-Bit Single-Core
- Mounting type
- Surface Mount
- Oscillator type
- Internal
- Program memory type
- FLASH
- Voltage - supply (Vcc (Vdd))
- 1.71V ~ 3.6V
Request a quote on any NXP Semiconductors MK22 Series part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.
Frequently asked questions
- How do the NXP Semiconductors NXP Semiconductors MK22 Series variants differ?
- NXP Semiconductors MK22 Series part numbers differ by case, connectivity, data converters and number of i (O). Use the selection guide above to pick by case.
- How many NXP Semiconductors NXP Semiconductors MK22 Series part numbers are listed?
- 6 NXP Semiconductors NXP Semiconductors MK22 Series part numbers are listed, each with specifications and a datasheet where available.
- How do I get pricing and lead time for NXP Semiconductors NXP Semiconductors MK22 Series?
- Request a quote (RFQ) for any NXP Semiconductors MK22 Series part number and we confirm price, availability and lead time per line — including end-of-life and hard-to-find variants.
