BAP64-02,115
NXP Semiconductors
Tape & Reel (TR); Cut Tape (CT)-65°C ~ 150°C (TJ)
Ref. price$0.39
Lead time on requestGet quote
NXP Semiconductors BAP64 Series
4 variants · NXP Semiconductors
About the NXP Semiconductors BAP64 Series
The NXP Semiconductors BAP64 Series series groups 4 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. The listed variants share a common capacitance @ vr, of 0.35pF @ 20V, 1MHz, current - max of 100 mA and operating temperature of -65°C ~ 150°C (TJ). Variants differ by case, diode type and power dissipation, so you can match the exact case your application requires using the selection guide below.
Select a variant by
- Case
- SC-70, SOT-323 · SC-79, SOD-523
- Diode type
- PIN - 1 Pair Common Cathode · PIN - 1 Pair Series Connection · PIN - Single
- Power dissipation
- 240 mW · 715 mW
- Voltage - peak reverse
- 100V · 175V
Shared specifications
- Capacitance @ vr,
- 0.35pF @ 20V, 1MHz
- Current - max
- 100 mA
- Operating temperature
- -65°C ~ 150°C (TJ)
- Package
- Tape & Reel (TR); Cut Tape (CT)
- Resistance @ if,
- 1.35Ohm @ 100mA, 100MHz
Variant comparison
| Parameter | BAP64-02,115 | BAP64-04W,115 | BAP64-05W,115 |
|---|---|---|---|
| Case | SC-79, SOD-523 | SC-70, SOT-323 | SC-70, SOT-323 |
| Diode type | PIN - Single | PIN - 1 Pair Series Connection | PIN - 1 Pair Common Cathode |
| Power dissipation | 715 mW | 240 mW | 240 mW |
| Voltage - peak reverse | 175V | 100V | 100V |
Request a quote on any NXP Semiconductors BAP64 Series part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.
