74HC107D,652
Nexperia USA Inc.
Tube-40°C~125°C(TA)85 MHz
Ref. price$0.17
Lead time on requestGet quote ›
NXP Semiconductors 74HC Series
36 variants · NXP Semiconductors
About the NXP Semiconductors NXP Semiconductors 74HC Series series
The NXP Semiconductors NXP Semiconductors 74HC Series series groups 36 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. The listed variants share a common input capacitance of 3.5 pF, mounting type of Surface Mount and voltage of 2V ~ 6V. Variants differ by case, current - output high, low and current - quiescent, so you can match the exact case your application requires using the selection guide below.
Select a variant by
- Case
- 14-SOIC (0.154\", 3.90mm Width) · 14-SSOP (0.209\", 5.30mm Width) · 16-SOIC (0.154\", 3.90mm Width) · 16-SSOP (0.209\", 5.30mm Width) · 20-SSOP (0.209\", 5.30mm Width)
- Current - output high, low
- 5.2mA, 5.2mA · 7.8mA, 7.8mA
- Current - quiescent
- 4 µA · 8 µA · 40 µA
- Frequency
- 81 MHz · 82 MHz · 85 MHz · 122 MHz · 133 MHz
- Function
- Master Reset · Reset · Set(Preset) and Reset · Standard
- Max propagation delay @ v, max CL
- 26ns @ 6V, 50pF · 27ns @ 6V, 50pF · 30ns @ 6V, 50pF · 37ns @ 6V, 50pF
- Number of bits per element
- 1 · 8
- Number of elements
- 1 · 2
Variant comparison
| Parameter | 74HC107D,652 | 74HC109D,652 | 74HC109DB,112 | 74HC273DB,112 | 74HC574DB,112 | 74HC574DB,118 |
|---|---|---|---|---|---|---|
| Case | 14-SOIC (0.154\", 3.90mm Width) | 16-SOIC (0.154\", 3.90mm Width) | 16-SSOP (0.209\", 5.30mm Width) | 20-SSOP (0.209\", 5.30mm Width) | 20-SSOP (0.209\", 5.30mm Width) | 20-SSOP (0.209\", 5.30mm Width) |
| Current - output high, low | 5.2mA, 5.2mA | 5.2mA, 5.2mA | 5.2mA, 5.2mA | 5.2mA, 5.2mA | 7.8mA, 7.8mA | 7.8mA, 7.8mA |
| Current - quiescent | 4 µA | 4 µA | 4 µA | 8 µA | 8 µA | 8 µA |
| Frequency | 85 MHz | 81 MHz | 81 MHz | 122 MHz | 133 MHz | 133 MHz |
| Function | Reset | Set(Preset) and Reset | Set(Preset) and Reset | Master Reset | Standard | Standard |
| Max propagation delay @ v, max CL | 27ns @ 6V, 50pF | 30ns @ 6V, 50pF | 30ns @ 6V, 50pF | 26ns @ 6V, 50pF | 26ns @ 6V, 50pF | 26ns @ 6V, 50pF |
| Number of bits per element | 1 | 1 | 1 | 8 | 8 | 8 |
| Number of elements | 2 | 2 | 2 | 1 | 1 | 1 |
Shared specifications
- Input capacitance
- 3.5 pF
- Mounting type
- Surface Mount
- Voltage
- 2V ~ 6V
