LPC54114J256BD64QL
NXP USA Inc.
LPC54100TrayBrown-out Detect/Reset, DMA, POR, PWM, WDT
Ref. price$9.5000
Lead time on requestGet quote
NXP USA Inc. LPC54 Series
70 variants · NXP USA Inc.
About the NXP USA Inc. LPC54 Series
The NXP USA Inc. LPC54 Series series groups 70 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. The listed variants share a common data converters of A/D 12x12b, mounting of Surface Mount and oscillator type of Internal. Variants differ by case, connectivity and core processor, so you can match the exact case your application requires using the selection guide below.
Select a variant by
- Case
- 49-UFBGA, WLCSP · 64-LQFP · 100-TFBGA · 180-TFBGA
- Connectivity
- CANbus, EBI/EMI, Ethernet, I²C, MMC/SD/SDIO, SmartCard, SPI, SPIFI, UART/USART, USB · I²C, SPI, UART/USART · I²C, SPI, UART/USART, USB
- Core processor
- ARM® Cortex®-M4 · ARM® Cortex®-M4/M0+
- Core size
- 32-Bit Dual-Core · 32-Bit Single-Core
- Number of i (O)
- 39 · 50 · 64 · 137 · 145
- Operating temperature
- -40°C ~ 105°C (TA) · -40°C~105°C(TA)
- Package
- Bulk · Tape & Reel (TR) Cut Tape (CT) · Tray
- Peripherals
- Brown-out Detect/Reset, DMA, I²S, LCD, POR, PWM, WDT · Brown-out Detect/Reset, DMA, I²S, POR, PWM, WDT · Brown-out Detect/Reset, DMA, POR, PWM, WDT · Brown-out Detect/Reset, POR, PWM, WDT
Shared specifications
- Data converters
- A/D 12x12b
- Mounting
- Surface Mount
- Oscillator type
- Internal
Variant comparison
| Parameter | LPC54114J256BD64QL | LPC54114J256UK49Z | LPC54605J256ET180E | LPC54607J256ET180E | LPC54S016JET100E | LPC54S018J2MET180E |
|---|---|---|---|---|---|---|
| Case | 64-LQFP | 49-UFBGA, WLCSP | 180-TFBGA | 180-TFBGA | 100-TFBGA | 180-TFBGA |
| Connectivity | I²C, SPI, UART/USART, USB | I²C, SPI, UART/USART, USB | I²C, SPI, UART/USART, USB | I²C, SPI, UART/USART, USB | CANbus, EBI/EMI, Ethernet, I²C, MMC/SD/SDIO, SmartCard, SPI, SPIFI, UART/USART, USB | CANbus, EBI/EMI, Ethernet, I²C, MMC/SD/SDIO, SmartCard, SPI, SPIFI, UART/USART, USB |
| Core processor | ARM® Cortex®-M4/M0+ | ARM® Cortex®-M4/M0+ | ARM® Cortex®-M4 | ARM® Cortex®-M4 | ARM® Cortex®-M4 | ARM® Cortex®-M4 |
| Core size | 32-Bit Dual-Core | 32-Bit Dual-Core | 32-Bit Single-Core | 32-Bit Single-Core | 32-Bit Single-Core | 32-Bit Single-Core |
| Number of i (O) | 50 | 39 | 145 | 145 | 64 | 137 |
| Operating temperature | -40°C ~ 105°C (TA) | -40°C ~ 105°C (TA) | -40°C ~ 105°C (TA) | -40°C ~ 105°C (TA) | -40°C ~ 105°C (TA) | -40°C ~ 105°C (TA) |
| Package | Tray | Tape & Reel (TR) Cut Tape (CT) | Tray | Tray | Tray | Tray |
| Peripherals | Brown-out Detect/Reset, DMA, POR, PWM, WDT | Brown-out Detect/Reset, DMA, I²S, POR, PWM, WDT | Brown-out Detect/Reset, DMA, I²S, POR, PWM, WDT | Brown-out Detect/Reset, DMA, I²S, LCD, POR, PWM, WDT | Brown-out Detect/Reset, DMA, I²S, POR, PWM, WDT | Brown-out Detect/Reset, DMA, I²S, LCD, POR, PWM, WDT |
Request a quote on any NXP USA Inc. LPC54 Series part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.
