PDTC143EQC-QZ
Nexperia USA Inc.
Tape & Reel (TR); Cut Tape (CT)Automotive, AEC-Q101Surface Mount, Wettable Flank
Ref. price$0.2900
Lead time on requestGet quote ›
Nexperia USA Inc. PDTC143 Series
13 variants · Nexperia USA Inc.
About the Nexperia USA Inc. Nexperia USA Inc. PDTC143 Series series
The Nexperia USA Inc. Nexperia USA Inc. PDTC143 Series series groups 13 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. Every variant in the range shares a common current - collector (Ic) of 100 mA, resistor - base (R1) of 4.7 kOhms and transistor type of NPN - Pre-Biased. Variants differ by case, current - collector cutoff and DC current gain (hFE) (Min) @ ic, vce, so you can match the exact case your application requires using the selection guide below. All listed Nexperia USA Inc. PDTC143 Series part numbers are active and orderable.
Select a variant by
- Case
- 3-XDFN Exposed Pad · SC-70, SOT-323 · SC-101, SOT-883 · TO-236-3, SC-59, SOT-23-3
- Current - collector cutoff
- 1µA · 100nA
- DC current gain (hFE) (Min) @ ic, vce
- 30 @ 10mA, 5V · 50 @ 10mA, 5V · 100 @ 10mA, 5V · 200 @ 1mA, 5V
- Mounting type
- Surface Mount · Surface Mount, Wettable Flank
- Package
- Tape & Reel (TR) Cut Tape (CT) · Tape & Reel (TR); Cut Tape (CT)
- Vce saturation (Max) @ ib, ic
- 100mV @ 250µA, 5mA · 100mV @ 500µA, 10mA · 150mV @ 500µA, 10mA
- Power - max
- 200 mW · 250 mW · 340 mW · 360 mW
Variant comparison
| Parameter | PDTC143EQC-QZ | PDTC143ET,215 | PDTC143EU,115 | PDTC143TT,215 | PDTC143TU,115 | PDTC143XQB-QZ |
|---|---|---|---|---|---|---|
| Case | 3-XDFN Exposed Pad | TO-236-3, SC-59, SOT-23-3 | SC-70, SOT-323 | TO-236-3, SC-59, SOT-23-3 | SC-70, SOT-323 | 3-XDFN Exposed Pad |
| Current - collector cutoff | 1µA | 1µA | 1µA | 1µA | 1µA | 100nA |
| DC current gain (hFE) (Min) @ ic, vce | 30 @ 10mA, 5V | 30 @ 10mA, 5V | 30 @ 10mA, 5V | 200 @ 1mA, 5V | 200 @ 1mA, 5V | 50 @ 10mA, 5V |
| Mounting type | Surface Mount, Wettable Flank | Surface Mount | Surface Mount | Surface Mount | Surface Mount | Surface Mount, Wettable Flank |
| Package | Tape & Reel (TR); Cut Tape (CT) | Tape & Reel (TR) Cut Tape (CT) | Tape & Reel (TR); Cut Tape (CT) | Tape & Reel (TR); Cut Tape (CT) | Tape & Reel (TR) Cut Tape (CT) | Tape & Reel (TR); Cut Tape (CT) |
| Vce saturation (Max) @ ib, ic | 150mV @ 500µA, 10mA | 150mV @ 500µA, 10mA | 150mV @ 500µA, 10mA | 100mV @ 250µA, 5mA | 100mV @ 250µA, 5mA | 100mV @ 500µA, 10mA |
| Power - max | — | 250 mW | 200 mW | 250 mW | 200 mW | 340 mW |
Shared specifications
- Current - collector (Ic)
- 100 mA
- Resistor - base (R1)
- 4.7 kOhms
- Transistor type
- NPN - Pre-Biased
- Voltage - collector emitter breakdown
- 50 V
Request a quote on any Nexperia USA Inc. PDTC143 Series part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.
Frequently asked questions
- How do the Nexperia USA Inc. Nexperia USA Inc. PDTC143 Series variants differ?
- Nexperia USA Inc. PDTC143 Series part numbers differ by case, current - collector cutoff, DC current gain (hFE) (Min) @ ic, vce and mounting type. Use the selection guide above to pick by case.
- How many Nexperia USA Inc. Nexperia USA Inc. PDTC143 Series part numbers are listed?
- 13 Nexperia USA Inc. Nexperia USA Inc. PDTC143 Series part numbers are listed, each with specifications and a datasheet where available.
- How do I get pricing and lead time for Nexperia USA Inc. Nexperia USA Inc. PDTC143 Series?
- Request a quote (RFQ) for any Nexperia USA Inc. PDTC143 Series part number and we confirm price, availability and lead time per line — including end-of-life and hard-to-find variants.
