74LVC1G3157GM,115
Nexperia USA Inc.
Tape & Reel (TR) Cut Tape (CT)-40°C ~ 125°C (TA)74LVC
Ref. price$0.3500
Lead time on requestGet quote ›
Nexperia USA Inc. 74LV Series
39 variants · Nexperia USA Inc.
About the Nexperia USA Inc. Nexperia USA Inc. 74LV Series series
The Nexperia USA Inc. Nexperia USA Inc. 74LV Series series groups 39 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. The listed variants share a common charge injection of 7.5pC, crosstalk of - and mounting type of Surface Mount. Variants differ by -3db bandwidth, case and channel capacitance (CS(off), CD(off)), so you can match the exact -3db bandwidth your application requires using the selection guide below.
Select a variant by
- -3db bandwidth
- 300MHz · 500MHz
- Case
- 5-TSSOP, SC-70-5, SOT-353 · 6-TSSOP, SC-88, SOT-363 · 6-XFDFN · SC-74, SOT-457 · SC-74A, SOT-753
- Channel capacitance (CS(off), CD(off))
- 5pF · 6pF
- Current - leakage (IS(off))
- 5µA · 500nA
- Multiplexer (Demultiplexer circuit)
- 1:1 · 2:1
- Operating temperature
- -40°C ~ 125°C (TA) · -40°C~125°C(TA)
- Package
- Tape & Reel (TR) Cut Tape (CT) · Tape & Reel (TR); Cut Tape (CT)
Variant comparison
| Parameter | 74LVC1G3157GM,115 | 74LVC1G3157GM,132 | 74LVC1G3157GM-Q10X | 74LVC1G3157GS,132 | 74LVC1G3157GV,125 | 74LVC1G3157GV-Q10H |
|---|---|---|---|---|---|---|
| -3db bandwidth | 300MHz | 300MHz | 300MHz | 300MHz | 300MHz | 300MHz |
| Case | 6-XFDFN | 6-XFDFN | 6-XFDFN | 6-XFDFN | SC-74, SOT-457 | SC-74, SOT-457 |
| Channel capacitance (CS(off), CD(off)) | 6pF | 6pF | 6pF | 6pF | 6pF | 6pF |
| Current - leakage (IS(off)) | 5µA | 5µA | 5µA | 5µA | 5µA | 5µA |
| Multiplexer (Demultiplexer circuit) | 2:1 | 2:1 | 2:1 | 2:1 | 2:1 | 2:1 |
| Operating temperature | -40°C ~ 125°C (TA) | -40°C ~ 125°C (TA) | -40°C~125°C(TA) | -40°C ~ 125°C (TA) | -40°C ~ 125°C (TA) | -40°C~125°C(TA) |
| Package | Tape & Reel (TR) Cut Tape (CT) | Tape & Reel (TR) Cut Tape (CT) | Tape & Reel (TR); Cut Tape (CT) | Tape & Reel (TR) Cut Tape (CT) | Tape & Reel (TR) Cut Tape (CT) | Tape & Reel (TR); Cut Tape (CT) |
Shared specifications
- Charge injection
- 7.5pC
- Crosstalk
- -
- Mounting type
- Surface Mount
- Number of circuits
- 1
- On-State resistance
- 10Ohm
- Voltage - supply, dual (V±)
- -
- Voltage - supply, single (V+)
- 1.65V ~ 5.5V
Request a quote on any Nexperia USA Inc. 74LV Series part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.
Frequently asked questions
- How do the Nexperia USA Inc. Nexperia USA Inc. 74LV Series variants differ?
- Nexperia USA Inc. 74LV Series part numbers differ by -3db bandwidth, case, channel capacitance (CS(off), CD(off)) and current - leakage (IS(off)). Use the selection guide above to pick by -3db bandwidth.
- How many Nexperia USA Inc. Nexperia USA Inc. 74LV Series part numbers are listed?
- 39 Nexperia USA Inc. Nexperia USA Inc. 74LV Series part numbers are listed, each with specifications and a datasheet where available.
- How do I get pricing and lead time for Nexperia USA Inc. Nexperia USA Inc. 74LV Series?
- Request a quote (RFQ) for any Nexperia USA Inc. 74LV Series part number and we confirm price, availability and lead time per line — including end-of-life and hard-to-find variants.
