74LV14ABZZ
Nexperia USA Inc.
2V ~ 5.5VTape & Reel (TR) Cut Tape (CT)-40°C ~ 125°C
Ref. price$0.5700
Lead time on requestGet quote ›
Nexperia USA Inc. 74LV Series
219 variants · Nexperia USA Inc.
About the Nexperia USA Inc. Nexperia USA Inc. 74LV Series series
The Nexperia USA Inc. Nexperia USA Inc. 74LV Series series groups 219 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. The listed variants share a common mounting type of Surface Mount. Variants differ by case, current - output high, low and current - quiescent, so you can match the exact case your application requires using the selection guide below.
Select a variant by
- Case
- 5-TSSOP, SC-70-5, SOT-353 · 6-XFDFN · 14-SOIC (0.154\", 3.90mm Width) · 14-TSSOP (0.173\", 4.40mm Width) · 14-VFQFN Exposed Pad · 14-XFQFN Exposed Pad · SC-74A, SOT-753
- Current - output high, low
- 12mA, 12mA · 24mA, 24mA · 32mA, 32mA
- Current - quiescent
- 2 µA · 4 µA · 40 µA
- Features
- - · Schmitt Trigger
- Input logic level - high
- 1.08V ~ 2V · 1.4V ~ 3.85V · 1.7V ~ 2V · 1.75V ~ 3.5V
- Input logic level - low
- 0.12V ~ 0.8V · 0.3V ~ 1.1V · 0.7V ~ 0.8V · 0.75V ~ 1.5V
- Logic type
- Inverter · NAND Gate
- Max propagation delay @ v, max CL
- 4ns @ 5V, 50pF · 4.5ns @ 3.3V, 50pF · 10.6ns @ 5V, 50pF · 15ns @ 3.3V, 50pF
Variant comparison
| Parameter | 74LV14ABZZ | 74LV14BQ,115 | 74LV14D,118 | 74LV14PW,118 | 74LVC04ABQ,115 | 74LVC04AD,118 |
|---|---|---|---|---|---|---|
| Case | 14-XFQFN Exposed Pad | 14-VFQFN Exposed Pad | 14-SOIC (0.154\", 3.90mm Width) | 14-TSSOP (0.173\", 4.40mm Width) | 14-VFQFN Exposed Pad | 14-SOIC (0.154\", 3.90mm Width) |
| Current - output high, low | 12mA, 12mA | 12mA, 12mA | 12mA, 12mA | 12mA, 12mA | 24mA, 24mA | 24mA, 24mA |
| Current - quiescent | 2 µA | 40 µA | 40 µA | 40 µA | 40 µA | 40 µA |
| Features | Schmitt Trigger | Schmitt Trigger | Schmitt Trigger | Schmitt Trigger | - | - |
| Input logic level - high | 1.75V ~ 3.5V | 1.4V ~ 3.85V | 1.4V ~ 3.85V | 1.4V ~ 3.85V | 1.08V ~ 2V | 1.08V ~ 2V |
| Input logic level - low | 0.75V ~ 1.5V | 0.3V ~ 1.1V | 0.3V ~ 1.1V | 0.3V ~ 1.1V | 0.12V ~ 0.8V | 0.12V ~ 0.8V |
| Logic type | Inverter | Inverter | Inverter | Inverter | Inverter | Inverter |
| Max propagation delay @ v, max CL | 10.6ns @ 5V, 50pF | 15ns @ 3.3V, 50pF | 15ns @ 3.3V, 50pF | 15ns @ 3.3V, 50pF | 4.5ns @ 3.3V, 50pF | 4.5ns @ 3.3V, 50pF |
