TC4420CAT
Microchip Technology
Tube0°C~150°C(TJ)N-Channel, P-Channel MOSFET
Ref. price$3.9900
Lead time on requestGet quote ›
Microchip Technology TC44 Series
85 variants · Microchip Technology
About the Microchip Technology Microchip Technology TC44 Series series
The Microchip Technology Microchip Technology TC44 Series series groups 85 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. The listed variants share a common driven configuration of Low-Side, gate type of N-Channel, P-Channel MOSFET and input type of Non-Inverting. Variants differ by case, channel type and current - peak output (Source, sink), so you can match the exact case your application requires using the selection guide below.
Select a variant by
- Case
- 8-DIP (0.300\", 7.62mm) · 8-SOIC (0.154\", 3.90mm Width) · 8-TSSOP, 8-MSOP (0.118\", 3.00mm Width) · TO-220-5
- Channel type
- Independent · Single
- Current - peak output (Source, sink)
- 1.5A, 1.5A · 6A, 6A
- Mounting type
- Surface Mount · Through Hole
- Number of drivers
- 1 · 2
- Operating temperature
- -40°C ~ 85°C (TA) · -40°C~85°C(TA) · -40°C~150°C(TJ) · 0°C~70°C(TA) · 0°C~150°C(TJ)
- Package
- Tape & Reel (TR); Cut Tape (CT) · Tube
Variant comparison
| Parameter | TC4420CAT | TC4420COA713 | TC4420EOA713 | TC4420EPA | TC4420VOA713 | TC4420VPA |
|---|---|---|---|---|---|---|
| Case | TO-220-5 | 8-SOIC (0.154\", 3.90mm Width) | 8-SOIC (0.154\", 3.90mm Width) | 8-DIP (0.300\", 7.62mm) | 8-SOIC (0.154\", 3.90mm Width) | 8-DIP (0.300\", 7.62mm) |
| Channel type | Single | Single | Single | Single | Single | Single |
| Current - peak output (Source, sink) | 6A, 6A | 6A, 6A | 6A, 6A | 6A, 6A | 6A, 6A | 6A, 6A |
| Mounting type | Through Hole | Surface Mount | Surface Mount | Through Hole | Surface Mount | Through Hole |
| Number of drivers | 1 | 1 | 1 | 1 | 1 | 1 |
| Operating temperature | 0°C~150°C(TJ) | 0°C~150°C(TJ) | -40°C~150°C(TJ) | -40°C~150°C(TJ) | -40°C~150°C(TJ) | -40°C~150°C(TJ) |
| Package | Tube | Tape & Reel (TR); Cut Tape (CT) | Tape & Reel (TR); Cut Tape (CT) | Tube | Tape & Reel (TR); Cut Tape (CT) | Tube |
Shared specifications
- Driven configuration
- Low-Side
- Gate type
- N-Channel, P-Channel MOSFET
- Input type
- Non-Inverting
- Logic voltage - VIL, VIH
- 0.8V, 2.4V
- Rise (Fall time)
- 25ns, 25ns
- Voltage
- 4.5V ~ 18V
Request a quote on any Microchip Technology TC44 Series part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.
