MCP3008-I/P
Microchip Technology
Tube-40°C~85°CSPI
Ref. price$3.1500
Lead time on requestGet quote ›
Microchip Technology MCP3 Series
115 variants · Microchip Technology
About the Microchip Technology Microchip Technology MCP3 Series series
The Microchip Technology Microchip Technology MCP3 Series series groups 115 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. The listed variants share a common number of a (D converters) of 1, voltage - supply, analog of 2.7V ~ 5.5V and voltage - supply, digital of 2.7V ~ 5.5V. Variants differ by architecture, case and configuration, so you can match the exact architecture your application requires using the selection guide below.
Select a variant by
- Architecture
- SAR · Sigma-Delta
- Case
- 14-SOIC (0.154\", 3.90mm Width) · 16-DIP (0.300\", 7.62mm) · 16-SOIC (0.154\", 3.90mm Width) · SOT-23-6
- Configuration
- MUX-PGA-ADC · MUX-S/H-ADC · PGA-ADC
- Features
- - · PGA · PGA, Selectable Address
- Input type
- Differential · Pseudo-Differential, Single Ended
- Interface
- I²C · SPI
- Mounting type
- Surface Mount · Through Hole
- Number of bits
- 10 · 12 · 18
Variant comparison
| Parameter | MCP3008-I/P | MCP3008-I/SL | MCP3008T-I/SL | MCP3208-BI/P | MCP3208-BI/SL | MCP3208-CI/P |
|---|---|---|---|---|---|---|
| Architecture | SAR | SAR | SAR | SAR | SAR | SAR |
| Case | 16-DIP (0.300\", 7.62mm) | 16-SOIC (0.154\", 3.90mm Width) | 16-SOIC (0.154\", 3.90mm Width) | 16-DIP (0.300\", 7.62mm) | 16-SOIC (0.154\", 3.90mm Width) | 16-DIP (0.300\", 7.62mm) |
| Configuration | MUX-S/H-ADC | MUX-S/H-ADC | MUX-S/H-ADC | MUX-S/H-ADC | MUX-S/H-ADC | MUX-S/H-ADC |
| Features | - | - | - | - | - | - |
| Input type | Pseudo-Differential, Single Ended | Pseudo-Differential, Single Ended | Pseudo-Differential, Single Ended | Pseudo-Differential, Single Ended | Pseudo-Differential, Single Ended | Pseudo-Differential, Single Ended |
| Interface | SPI | SPI | SPI | SPI | SPI | SPI |
| Mounting type | Through Hole | Surface Mount | Surface Mount | Through Hole | Surface Mount | Through Hole |
| Number of bits | 10 | 10 | 10 | 12 | 12 | 12 |
Shared specifications
- Number of a (D converters)
- 1
- Voltage - supply, analog
- 2.7V ~ 5.5V
- Voltage - supply, digital
- 2.7V ~ 5.5V
Request a quote on any Microchip Technology MCP3 Series part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.
Frequently asked questions
- How do the Microchip Technology Microchip Technology MCP3 Series variants differ?
- Microchip Technology MCP3 Series part numbers differ by architecture, case, configuration and features. Use the selection guide above to pick by architecture.
- How many Microchip Technology Microchip Technology MCP3 Series part numbers are listed?
- 115 Microchip Technology Microchip Technology MCP3 Series part numbers are listed, each with specifications and a datasheet where available.
- How do I get pricing and lead time for Microchip Technology Microchip Technology MCP3 Series?
- Request a quote (RFQ) for any Microchip Technology MCP3 Series part number and we confirm price, availability and lead time per line — including end-of-life and hard-to-find variants.
