LM4040CYM3-5.0-TR
Microchip Technology
Tape & Reel (TR); Cut Tape (CT)±0.5%80µVrms
Ref. price$0.3900
Lead time on requestGet quote ›
Microchip Technology LM40 Series
8 variants · Microchip Technology
About the Microchip Technology Microchip Technology LM40 Series series
The Microchip Technology Microchip Technology LM40 Series series groups 8 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. Every variant in the range shares a common case of TO-236-3, SC-59, SOT-23-3, current - supply of - and mounting type of Surface Mount. Variants differ by current - cathode, current - output and noise - 10Hz to 10kHz, so you can match the exact current - cathode your application requires using the selection guide below. All listed Microchip Technology LM40 Series part numbers are active and orderable.
Select a variant by
- Current - cathode
- 65 µA · 70 µA · 78 µA · 80 µA · 85 µA
- Current - output
- 12 mA · 15 mA · 20 mA
- Noise - 10Hz to 10kHz
- 20µVrms · 80µVrms
- Output type
- Adjustable · Fixed
- Package
- Bulk · Tape & Reel (TR); Cut Tape (CT)
- Temperature coefficient
- 100ppm/°C · 150ppm/°C
- Tolerance
- ±0.1% · ±0.5% · ±1%
- Voltage - output (Min (Fixed))
- 1.225V · 1.233V · 4.096V · 5V
Variant comparison
| Parameter | LM4040CYM3-5.0-TR | LM4040DYM3-4.1-TR | LM4040DYM3-5.0-TR | LM4041CYM3-1.2-TR | LM4041DYM3-1.2-TR | LM4041DYM3-ADJ-TR |
|---|---|---|---|---|---|---|
| Current - cathode | 80 µA | 78 µA | 85 µA | 65 µA | 70 µA | 70 µA |
| Current - output | 15 mA | 15 mA | 15 mA | 12 mA | 12 mA | 12 mA |
| Noise - 10Hz to 10kHz | 80µVrms | 80µVrms | 80µVrms | 20µVrms | 20µVrms | 20µVrms |
| Output type | Fixed | Fixed | Fixed | Fixed | Fixed | Adjustable |
| Package | Tape & Reel (TR); Cut Tape (CT) | Tape & Reel (TR); Cut Tape (CT) | Tape & Reel (TR); Cut Tape (CT) | Tape & Reel (TR); Cut Tape (CT) | Tape & Reel (TR); Cut Tape (CT) | Tape & Reel (TR); Cut Tape (CT) |
| Temperature coefficient | 100ppm/°C | 150ppm/°C | 150ppm/°C | 100ppm/°C | 150ppm/°C | 150ppm/°C |
| Tolerance | ±0.5% | ±1% | ±1% | ±0.5% | ±1% | ±1% |
| Voltage - output (Min (Fixed)) | 5V | 4.096V | 5V | 1.225V | 1.225V | 1.233V |
Shared specifications
- Case
- TO-236-3, SC-59, SOT-23-3
- Current - supply
- -
- Mounting type
- Surface Mount
- Noise - 0.1Hz to 10Hz
- -
- Operating temperature
- -40°C~85°C(TA)
- Reference type
- Shunt
- Voltage - input
- -
Request a quote on any Microchip Technology LM40 Series part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.
Frequently asked questions
- How do the Microchip Technology Microchip Technology LM40 Series variants differ?
- Microchip Technology LM40 Series part numbers differ by current - cathode, current - output, noise - 10Hz to 10kHz and output type. Use the selection guide above to pick by current - cathode.
- How many Microchip Technology Microchip Technology LM40 Series part numbers are listed?
- 8 Microchip Technology Microchip Technology LM40 Series part numbers are listed, each with specifications and a datasheet where available.
- How do I get pricing and lead time for Microchip Technology Microchip Technology LM40 Series?
- Request a quote (RFQ) for any Microchip Technology LM40 Series part number and we confirm price, availability and lead time per line — including end-of-life and hard-to-find variants.
