MLX90614ESF-BAA-000-SP
Melexis Technologies NV
-40°C~85°CBulkPWM, SMBus
Ref. price$22.4800
Lead time on requestGet quote
Melexis Technologies NV MLX90614ESF Series
38 variants · Melexis Technologies NV
About the Melexis Technologies NV MLX90614ESF Series
The Melexis Technologies NV MLX90614ESF Series series groups 38 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. Every variant in the range shares a common case of TO-39-4 Metal Can, features of Sleep Mode and mounting of Through Hole. Variants differ by accuracy - highest (Lowest), operating temperature and package, so you can match the exact accuracy - highest (Lowest) your application requires using the selection guide below. All listed Melexis Technologies NV MLX90614ESF Series part numbers are active and orderable.
Select a variant by
- Accuracy - highest (Lowest)
- ±0.2°C (±0.3°C) · ±0.5°C (±4°C)
- Operating temperature
- -40°C ~ 85°C · -40°C~85°C
- Package
- Bulk · Tray · Tube
- Sensing temperature - local
- -40°C ~ 85°C · -40°C~85°C
- Sensing temperature - remote
- -70°C ~ 380°C (IR) · -70°C~380°C(IR)
- Test condition
- 0°C ~ 60°C (120°C ~ 380°C) · 0°C ~ 60°C (240°C ~ 380°C)
- Voltage
- 2.6V ~ 3.6V · 4.5V ~ 5.5V
Shared specifications
- Case
- TO-39-4 Metal Can
- Features
- Sleep Mode
- Mounting
- Through Hole
- Output type
- PWM, SMBus
- Resolution
- 16 b
- Sensor type
- Digital, Infrared (IR)
Variant comparison
| Parameter | MLX90614ESF-BAA-000-SP | MLX90614ESF-BCF-000-SP | MLX90614ESF-BCF-000-TU | MLX90614ESF-BCH-000-TU | MLX90614ESF-BCI-000-SP | MLX90614ESF-DCH-000-TU |
|---|---|---|---|---|---|---|
| Accuracy - highest (Lowest) | ±0.5°C (±4°C) | ±0.5°C (±4°C) | ±0.5°C (±4°C) | ±0.5°C (±4°C) | ±0.5°C (±4°C) | ±0.2°C (±0.3°C) |
| Operating temperature | -40°C~85°C | -40°C~85°C | -40°C~85°C | -40°C~85°C | -40°C~85°C | -40°C~85°C |
| Package | Bulk | Bulk | Tube | Tube | Bulk | Tube |
| Sensing temperature - local | -40°C~85°C | -40°C~85°C | -40°C~85°C | -40°C~85°C | -40°C~85°C | -40°C~85°C |
| Sensing temperature - remote | -70°C~380°C(IR) | -70°C~380°C(IR) | -70°C~380°C(IR) | -70°C~380°C(IR) | -70°C~380°C(IR) | -70°C~380°C(IR) |
| Test condition | 0°C ~ 60°C (120°C ~ 380°C) | 0°C ~ 60°C (120°C ~ 380°C) | 0°C ~ 60°C (120°C ~ 380°C) | 0°C ~ 60°C (120°C ~ 380°C) | 0°C ~ 60°C (120°C ~ 380°C) | 0°C ~ 60°C (120°C ~ 380°C) |
| Voltage | 2.6V ~ 3.6V | 2.6V ~ 3.6V | 2.6V ~ 3.6V | 2.6V ~ 3.6V | 2.6V ~ 3.6V | 2.6V ~ 3.6V |
Request a quote on any Melexis Technologies NV MLX90614ESF Series part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.
