MLX90614ESF-AAA-000-TU
Melexis Technologies NV
4.5V ~ 5.5VTray-40°C~85°C
Ref. price$22.4800
Lead time on requestGet quote ›
Melexis Technologies NV MLX9 Series
19 variants · Melexis Technologies NV
About the Melexis Technologies NV Melexis Technologies NV MLX9 Series series
The Melexis Technologies NV Melexis Technologies NV MLX9 Series series groups 19 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. The listed variants share a common case of TO-39-4 Metal Can, features of Sleep Mode and mounting type of Through Hole. Variants differ by accuracy - highest (Lowest), package and test condition, so you can match the exact accuracy - highest (Lowest) your application requires using the selection guide below.
Select a variant by
- Accuracy - highest (Lowest)
- ±0.2°C (±0.3°C) · ±0.5°C (±4°C)
- Package
- Bulk · Tray · Tube
- Test condition
- 0°C ~ 60°C (120°C ~ 380°C) · 0°C ~ 60°C (240°C ~ 380°C)
- Voltage
- 2.6V ~ 3.6V · 4.5V ~ 5.5V
Variant comparison
| Parameter | MLX90614ESF-AAA-000-TU | MLX90614ESF-ACF-000-TU | MLX90614ESF-BAA-000-SP | MLX90614ESF-BAA-000-TU | MLX90614ESF-BCF-000-SP | MLX90614ESF-BCF-000-TU |
|---|---|---|---|---|---|---|
| Accuracy - highest (Lowest) | ±0.5°C (±4°C) | ±0.5°C (±4°C) | ±0.5°C (±4°C) | ±0.5°C (±4°C) | ±0.5°C (±4°C) | ±0.5°C (±4°C) |
| Package | Tray | Tube | Bulk | Tube | Bulk | Tube |
| Test condition | 0°C ~ 60°C (240°C ~ 380°C) | 0°C ~ 60°C (240°C ~ 380°C) | 0°C ~ 60°C (120°C ~ 380°C) | 0°C ~ 60°C (120°C ~ 380°C) | 0°C ~ 60°C (120°C ~ 380°C) | 0°C ~ 60°C (120°C ~ 380°C) |
| Voltage | 4.5V ~ 5.5V | 4.5V ~ 5.5V | 2.6V ~ 3.6V | 2.6V ~ 3.6V | 2.6V ~ 3.6V | 2.6V ~ 3.6V |
Shared specifications
- Case
- TO-39-4 Metal Can
- Features
- Sleep Mode
- Mounting type
- Through Hole
- Operating temperature
- -40°C~85°C
- Output type
- PWM, SMBus
- Resolution
- 16 b
- Sensing temperature - local
- -40°C~85°C
- Sensing temperature - remote
- -70°C~380°C(IR)
- Sensor type
- Digital, Infrared (IR)
Request a quote on any Melexis Technologies NV MLX9 Series part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.
Frequently asked questions
- How do the Melexis Technologies NV Melexis Technologies NV MLX9 Series variants differ?
- Melexis Technologies NV MLX9 Series part numbers differ by accuracy - highest (Lowest), package, test condition and voltage. Use the selection guide above to pick by accuracy - highest (Lowest).
- How many Melexis Technologies NV Melexis Technologies NV MLX9 Series part numbers are listed?
- 19 Melexis Technologies NV Melexis Technologies NV MLX9 Series part numbers are listed, each with specifications and a datasheet where available.
- How do I get pricing and lead time for Melexis Technologies NV Melexis Technologies NV MLX9 Series?
- Request a quote (RFQ) for any Melexis Technologies NV MLX9 Series part number and we confirm price, availability and lead time per line — including end-of-life and hard-to-find variants.
