IRM-01-12
MEAN WELL USA Inc.
Through HoleIRM-01 (1W)Tube
Ref. price$6.6800
Lead time on requestGet quote
MEAN WELL USA Inc. IRM0 Series
41 variants · MEAN WELL USA Inc.
About the MEAN WELL USA Inc. IRM0 Series
The MEAN WELL USA Inc. IRM0 Series series groups 41 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. Every variant in the range shares a common applications of ITE (Commercial), approval agency of CB, CE, cURus, TUV and features of Universal Input. Variants differ by case, efficiency and mounting, so you can match the exact case your application requires using the selection guide below. All listed MEAN WELL USA Inc. IRM0 Series part numbers are active and orderable.
Select a variant by
- Case
- 4-DIP Module · 24-SMD Module, 14 Leads
- Efficiency
- 66% · 70% · 72% · 74% · 75% · 77%
- Mounting
- Surface Mount · Through Hole
- Operating temperature
- -30°C ~ 85°C (With Derating) · -30°C~85°C(WithDerating)
- Output current
- 42mA · 67mA · 83mA · 111mA · 200mA · 300mA
- Package
- Tray · Tube
- Size (Dimension)
- 1.33\" L x 0.87\" W x 0.59\" H (33.7mm x 22.2mm x 15.0mm) · 1.33\" L x 0.87\" W x 0.63\" H (33.7mm x 22.2mm x 16.0mm)
- Voltage - output 1
- 3.3V · 5V · 9V · 12V · 15V · 24V
Shared specifications
- Applications
- ITE (Commercial)
- Approval agency
- CB, CE, cURus, TUV
- Features
- Universal Input
- I/O channels
- 1
- Line regulation
- ±0.5%
- Load regulation
- ±0.5%
- Power (Watts)
- 1 W
- Type
- Enclosed
- Voltage - input
- 85 ~ 305 VAC, 120 ~ 430 VDC
- Voltage - output 2
- -
- Voltage - output 3
- -
- Voltage - output 4
- -
Variant comparison
| Parameter | IRM-01-12 | IRM-01-12S | IRM-01-15 | IRM-01-15S | IRM-01-24 | IRM-01-24S |
|---|---|---|---|---|---|---|
| Case | 4-DIP Module | 24-SMD Module, 14 Leads | 4-DIP Module | 24-SMD Module, 14 Leads | 4-DIP Module | 24-SMD Module, 14 Leads |
| Efficiency | 74% | 74% | 75% | 75% | 77% | 77% |
| Mounting | Through Hole | Surface Mount | Through Hole | Surface Mount | Through Hole | Surface Mount |
| Operating temperature | -30°C~85°C(WithDerating) | -30°C~85°C(WithDerating) | -30°C~85°C(WithDerating) | -30°C~85°C(WithDerating) | -30°C~85°C(WithDerating) | -30°C~85°C(WithDerating) |
| Output current | 83mA | 83mA | 67mA | 67mA | 42mA | 42mA |
| Package | Tube | Tube | Tube | Tube | Tube | Tube |
| Size (Dimension) | 1.33\" L x 0.87\" W x 0.59\" H (33.7mm x 22.2mm x 15.0mm) | 1.33\" L x 0.87\" W x 0.63\" H (33.7mm x 22.2mm x 16.0mm) | 1.33\" L x 0.87\" W x 0.59\" H (33.7mm x 22.2mm x 15.0mm) | 1.33\" L x 0.87\" W x 0.63\" H (33.7mm x 22.2mm x 16.0mm) | 1.33\" L x 0.87\" W x 0.59\" H (33.7mm x 22.2mm x 15.0mm) | 1.33\" L x 0.87\" W x 0.63\" H (33.7mm x 22.2mm x 16.0mm) |
| Voltage - output 1 | 12V | 12V | 15V | 15V | 24V | 24V |
