CNY17-1
Lite-On Inc.
-55°C ~ 100°CCNY17Tube
Ref. price$0.6600
Lead time on requestGet quote ›
Lite-On Inc. CNY17 Series
11 variants · Lite-On Inc.
About the Lite-On Inc. Lite-On Inc. CNY17 Series series
The Lite-On Inc. Lite-On Inc. CNY17 Series series groups 11 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. Every variant in the range shares a common current - DC forward (If) of 60 mA, input type of DC and number of channels of 1. Variants differ by case, current - output (Channel) and current transfer ratio, so you can match the exact case your application requires using the selection guide below. All listed Lite-On Inc. CNY17 Series part numbers are active and orderable.
Select a variant by
- Case
- 6-DIP (0.300\", 7.62mm) · 6-SMD, Gull Wing
- Current - output (Channel)
- 50mA · 150mA
- Current transfer ratio
- 80% @ 10mA · 125% @ 10mA · 200% @ 10mA · 320% @ 10mA
- Mounting type
- Surface Mount · Through Hole
- Operating temperature
- -55°C ~ 100°C · -55°C ~ 110°C · -55°C~100°C · -55°C~110°C
- Output type
- Transistor · Transistor with Base
- Rise (Fall time)
- 2µs, 2µs · 5µs, 5µs
Variant comparison
| Parameter | CNY17-1 | CNY17-1S | CNY17-2 | CNY17-3 | CNY17-3S | CNY17-4 |
|---|---|---|---|---|---|---|
| Case | 6-DIP (0.300\", 7.62mm) | 6-SMD, Gull Wing | 6-DIP (0.300\", 7.62mm) | 6-DIP (0.300\", 7.62mm) | 6-SMD, Gull Wing | 6-DIP (0.300\", 7.62mm) |
| Current - output (Channel) | 150mA | 150mA | 150mA | 50mA | 150mA | 50mA |
| Current transfer ratio | 80% @ 10mA | 80% @ 10mA | 125% @ 10mA | 200% @ 10mA | 200% @ 10mA | 320% @ 10mA |
| Mounting type | Through Hole | Surface Mount | Through Hole | Through Hole | Surface Mount | Through Hole |
| Operating temperature | -55°C ~ 100°C | -55°C ~ 100°C | -55°C ~ 100°C | -55°C ~ 110°C | -55°C~100°C | -55°C~110°C |
| Output type | Transistor with Base | Transistor with Base | Transistor with Base | Transistor with Base | Transistor with Base | Transistor with Base |
| Rise (Fall time) | 5µs, 5µs | 5µs, 5µs | 5µs, 5µs | 2µs, 2µs | 5µs, 5µs | 2µs, 2µs |
Shared specifications
- Current - DC forward (If)
- 60 mA
- Input type
- DC
- Number of channels
- 1
- Package
- Tube
- Voltage - isolation
- 5000Vrms
- Voltage - output
- 70V
Request a quote on any Lite-On Inc. CNY17 Series part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.
Frequently asked questions
- How do the Lite-On Inc. Lite-On Inc. CNY17 Series variants differ?
- Lite-On Inc. CNY17 Series part numbers differ by case, current - output (Channel), current transfer ratio and mounting type. Use the selection guide above to pick by case.
- How many Lite-On Inc. Lite-On Inc. CNY17 Series part numbers are listed?
- 11 Lite-On Inc. Lite-On Inc. CNY17 Series part numbers are listed, each with specifications and a datasheet where available.
- How do I get pricing and lead time for Lite-On Inc. Lite-On Inc. CNY17 Series?
- Request a quote (RFQ) for any Lite-On Inc. CNY17 Series part number and we confirm price, availability and lead time per line — including end-of-life and hard-to-find variants.
