IXDN609CI
IXYS Integrated Circuits Division
Through HoleTube< 24 V
Ref. price$3.75
Lead time on requestGet quote
IXYS Integrated Circuits Division IXDN Discrete Semiconductors Series
4 variants · IXYS Integrated Circuits Division
About the IXYS Integrated Circuits Division IXDN Discrete Semiconductors Series
The IXYS Integrated Circuits Division IXDN Discrete Semiconductors Series series groups 4 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. Every variant in the range shares a common channel type of Single, driven configuration of Low-Side and gate type of IGBT, N-Channel, P-Channel MOSFET. Variants differ by case, current - peak output (Source, sink) and logic voltage - VIL, VIH, so you can match the exact case your application requires using the selection guide below. All listed IXYS Integrated Circuits Division IXDN Discrete Semiconductors Series part numbers are active and orderable.
Select a variant by
- Case
- 8-SOIC (0.154\", 3.90mm Width) Exposed Pad · TO-220-5
- Current - peak output (Source, sink)
- 9A, 9A · 14A, 14A · 30A, 30A
- Logic voltage - VIL, VIH
- 0.8V, 3.5V · 0.8V, 3V
- Mounting
- Surface Mount · Through Hole
- Package
- Tape & Reel (TR); Cut Tape (CT) · Tube
- Rise (Fall time)
- 11ns, 11ns · 22ns, 15ns · 25ns, 18ns
- Voltage
- 4.5V ~ 35V · 12.5V ~ 35V
Shared specifications
- Channel type
- Single
- Driven configuration
- Low-Side
- Gate type
- IGBT, N-Channel, P-Channel MOSFET
- Input type
- Non-Inverting
- Number of drivers
- 1
- Operating temperature
- -55°C ~ 150°C (TJ)
Variant comparison
| Parameter | IXDN609CI | IXDN609SI | IXDN614SITR | IXDN630CI |
|---|---|---|---|---|
| Case | TO-220-5 | 8-SOIC (0.154\", 3.90mm Width) Exposed Pad | 8-SOIC (0.154\", 3.90mm Width) Exposed Pad | TO-220-5 |
| Current - peak output (Source, sink) | 9A, 9A | 9A, 9A | 14A, 14A | 30A, 30A |
| Logic voltage - VIL, VIH | 0.8V, 3V | 0.8V, 3V | 0.8V, 3V | 0.8V, 3.5V |
| Mounting | Through Hole | Surface Mount | Surface Mount | Through Hole |
| Package | Tube | Tube | Tape & Reel (TR); Cut Tape (CT) | Tube |
| Rise (Fall time) | 22ns, 15ns | 22ns, 15ns | 25ns, 18ns | 11ns, 11ns |
| Voltage | 4.5V ~ 35V | 4.5V ~ 35V | 4.5V ~ 35V | 12.5V ~ 35V |
Request a quote on any IXYS Integrated Circuits Division IXDN Discrete Semiconductors Series part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.
