Specifications
| Parameter | Value |
|---|---|
| Series | 76 |
| Actuation | Rocker |
| Mounting | Through Hole |
| Voltage rating | 30VDC |
| Current rating | 150mA |
| Operating temperature | -40°C~85°C |
| Body material | Thermoplastic |
| Contact material | Copper Alloy |
| Height above board | 0.315\" (8.00mm) |
| Electrical life | 2,000 Cycles |
| Mechanical life | 2,000 Cycles |
| Pitch | 0.100\" (2.54mm), Full |
All specifications
| Parameter | Value |
|---|---|
| Length | 1.080\" (27.43mm) |
| Circuit | SPST |
| Package | Tube |
| Features | Tape Seal |
| Washable | Yes |
| Actuator level | Raised |
| Contact finish | Gold |
| Termination style | PC Pin |
| Positions | 10 |
