ECS-200-10-36-JGN-TR
ECS Inc.
Surface MountECX-22360.026\" (0.65mm)
Ref. price$0.3604
Lead time on requestGet quote
ECS Inc. ECS2 Series
1352 variants · ECS Inc.
About the ECS Inc. ECS2 Series
The ECS Inc. ECS2 Series series groups 1352 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. The listed variants share a common ratings of -. Variants differ by case, frequency and frequency stability, so you can match the exact case your application requires using the selection guide below.
Select a variant by
- Case
- 2-SMD, No Lead · 4-SMD, No Lead · 8-DIP, 4 Leads (Half Size, Metal Can) · HC-49/US
- Frequency
- 4 MHz · 11.0592 MHz · 12 MHz · 16 MHz · 18 MHz · 18.432 MHz · 20 MHz · 20.3563 MHz · 22.1184 MHz
- Frequency stability
- ±10ppm · ±30ppm · ±50ppm · ±100ppm
- Height - seated
- 0.026\" (0.65mm) · 0.031\" (0.80mm) · 0.043\" (1.10mm) · 0.138\" (3.50mm) · 0.169\" (4.30mm) · 0.213\" (5.40mm)
- Mounting
- Surface Mount · Through Hole
- Operating temperature
- -55°C ~ 125°C · -40°C ~ 85°C · -40°C~85°C · -30°C~85°C · -10°C~70°C · 0°C ~ 70°C · 0°C~70°C
- Package
- Bulk · Tape & Reel (TR) · Tape & Reel (TR) Cut Tape (CT) · Tape & Reel (TR); Cut Tape (CT)
Shared specifications
- Ratings
- -
Variant comparison
| Parameter | ECS-200-10-36-JGN-TR | ECS-200-20-33-DU-TR | ECS-200-9-33B-CKY-TR | ECS-203.563-CD-0375TR | ECS-2100A-180 | ECS-2100AX-110.5 |
|---|---|---|---|---|---|---|
| Case | 4-SMD, No Lead | 4-SMD, No Lead | 4-SMD, No Lead | HC-49/US | 8-DIP, 4 Leads (Half Size, Metal Can) | 8-DIP, 4 Leads (Half Size, Metal Can) |
| Frequency | 20 MHz | 20 MHz | 20 MHz | 20.3563 MHz | 18 MHz | 11.0592 MHz |
| Frequency stability | ±30ppm | ±100ppm | ±10ppm | ±30ppm | ±100ppm | ±100ppm |
| Height - seated | 0.026\" (0.65mm) | 0.031\" (0.80mm) | 0.031\" (0.80mm) | 0.169\" (4.30mm) | 0.213\" (5.40mm) | 0.213\" (5.40mm) |
| Mounting | Surface Mount | Surface Mount | Surface Mount | Surface Mount | Through Hole | Through Hole |
| Operating temperature | -40°C~85°C | -55°C ~ 125°C | -30°C~85°C | -10°C~70°C | 0°C ~ 70°C | 0°C~70°C |
| Package | Tape & Reel (TR); Cut Tape (CT) | Tape & Reel (TR) Cut Tape (CT) | Tape & Reel (TR); Cut Tape (CT) | Tape & Reel (TR) | Bulk | Bulk |
Request a quote on any ECS Inc. ECS2 Series part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.
