Diodes Incorporated ZXTN Series

40 variants · Diodes Incorporated

About the Diodes Incorporated Diodes Incorporated ZXTN Series series

The Diodes Incorporated Diodes Incorporated ZXTN Series series groups 40 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. The listed variants share a common mounting type of Surface Mount, operating temperature of -55°C ~ 150°C (TJ) and package of Tape & Reel (TR); Cut Tape (CT). Variants differ by case, current - collector (Ic) and current - collector cutoff, so you can match the exact case your application requires using the selection guide below.

Select a variant by

Case: 3-UDFN · TO-236-3, SC-59, SOT-23-3
Current - collector (Ic): 4 A · 5 A
Current - collector cutoff: 20nA (ICBO) · 25nA
DC current gain (hFE) (Min) @ ic, vce: 100 @ 2A, 1V · 100 @ 2A, 2V
Frequency: 130MHz · 165MHz
Power - max: 1.2 W · 3 W
Vce saturation (Max) @ ib, ic: 210mV @ 300mA, 6A · 320mV @ 200mA, 4A
Voltage - collector emitter breakdown: 50 V · 60 V

Variant comparison

Parameter	ZXTN2018FTA	ZXTN619MATA
Case	TO-236-3, SC-59, SOT-23-3	3-UDFN
Current - collector (Ic)	5 A	4 A
Current - collector cutoff	20nA (ICBO)	25nA
DC current gain (hFE) (Min) @ ic, vce	100 @ 2A, 1V	100 @ 2A, 2V
Frequency	130MHz	165MHz
Power - max	1.2 W	3 W
Vce saturation (Max) @ ib, ic	210mV @ 300mA, 6A	320mV @ 200mA, 4A
Voltage - collector emitter breakdown	60 V	50 V

Shared specifications

Mounting type: Surface Mount
Operating temperature: -55°C ~ 150°C (TJ)
Package: Tape & Reel (TR); Cut Tape (CT)
Transistor type: NPN

Request a quote on any Diodes Incorporated ZXTN Series part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.
