DMP3007LSS-13
Diodes Incorporated
Tape & Reel (TR) Cut Tape (CT)P-Channel±25V
Ref. price$0.9100
Lead time on requestGet quote ›
Diodes Incorporated DMP3 Series
63 variants · Diodes Incorporated
About the Diodes Incorporated Diodes Incorporated DMP3 Series series
The Diodes Incorporated Diodes Incorporated DMP3 Series series groups 63 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. The listed variants share a common drain to source voltage of 30 V, FET feature of - and FET type of P-Channel. Variants differ by case, current - continuous drain (Id) @ 25°C and drive voltage (Max rds on, min rds on), so you can match the exact case your application requires using the selection guide below.
Select a variant by
- Case
- 8-PowerTDFN · 8-PowerVDFN · 8-SOIC (0.154\", 3.90mm Width) · TO-252-3, DPak (2 Leads + Tab), SC-63
- Current - continuous drain (Id) @ 25°C
- 8.6A (Ta) · 14A (Ta) · 17A (Ta) · 19.8A (Ta), 50A (Tc) · 36A (Ta) · 50A (Tc) · 70A (Tc) · 90A (Tc)
- Drive voltage (Max rds on, min rds on)
- 4V, 10V · 4.5V, 10V
- Gate charge (Qg) (Max) @ vgs
- 46 nC @ 10 V · 47 nC @ 10 V · 59.2 nC @ 4.5 V · 64.2 nC @ 10 V · 126.2 nC @ 10 V
- Input capacitance (Ciss) (Max) @ vds
- 2230 pF @ 15 V · 2380 pF @ 15 V · 2826 pF @ 15 V · 6234 pF @ 15 V
- Power dissipation
- 1W (Ta) · 1.4W (Ta) · 1.7W (Ta) · 2.18W (Ta) · 2.4W (Ta) · 2.7W (Ta) · 2.8W (Ta) · 900mW (Ta) · 980mW (Ta)
- Rds on (Max) @ id, vgs
- 6mOhm @ 11.5A, 10V · 6.8mOhm @ 11.5A, 10V · 7mOhm @ 15A, 10V · 7mOhm @ 17A, 10V · 7.5mOhm @ 10A, 10V · 8mOhm @ 10A, 10V · 10mOhm @ 11.5A, 10V · 17mOhm @ 10A, 10V
- Vgs
- ±20V · ±25V
Variant comparison
| Parameter | DMP3007LSS-13 | DMP3007SCG-13 | DMP3007SCG-7 | DMP3007SCGQ-7 | DMP3007SFG-13 | DMP3007SFG-7 |
|---|---|---|---|---|---|---|
| Case | 8-SOIC (0.154\", 3.90mm Width) | 8-PowerVDFN | 8-PowerVDFN | 8-PowerVDFN | 8-PowerVDFN | 8-PowerVDFN |
| Current - continuous drain (Id) @ 25°C | 14A (Ta) | 50A (Tc) | 50A (Tc) | 50A (Tc) | 70A (Tc) | 70A (Tc) |
| Drive voltage (Max rds on, min rds on) | 4V, 10V | 4.5V, 10V | 4.5V, 10V | 4.5V, 10V | 4.5V, 10V | 4.5V, 10V |
| Gate charge (Qg) (Max) @ vgs | 64.2 nC @ 10 V | 64.2 nC @ 10 V | 64.2 nC @ 10 V | 64.2 nC @ 10 V | 64.2 nC @ 10 V | 64.2 nC @ 10 V |
| Input capacitance (Ciss) (Max) @ vds | 2826 pF @ 15 V | 2826 pF @ 15 V | 2826 pF @ 15 V | 2826 pF @ 15 V | 2826 pF @ 15 V | 2826 pF @ 15 V |
| Power dissipation | 1.4W (Ta) | 2.4W (Ta) | 2.4W (Ta) | 1W (Ta) | 2.8W (Ta) | 2.8W (Ta) |
| Rds on (Max) @ id, vgs | 7mOhm @ 17A, 10V | 6.8mOhm @ 11.5A, 10V | 6.8mOhm @ 11.5A, 10V | 6.8mOhm @ 11.5A, 10V | 6mOhm @ 11.5A, 10V | 6mOhm @ 11.5A, 10V |
| Vgs | ±25V | ±25V | ±25V | ±25V | ±25V | ±25V |
Shared specifications
- Drain to source voltage
- 30 V
- FET feature
- -
- FET type
- P-Channel
- Mounting type
- Surface Mount
- Operating temperature
- -55°C ~ 150°C (TJ)
- Package
- Tape & Reel (TR) Cut Tape (CT)
- Technology
- MOSFET (Metal Oxide)
