Diodes Incorporated DMN1 Series

10 variants · Diodes Incorporated

About the Diodes Incorporated Diodes Incorporated DMN1 Series series

The Diodes Incorporated Diodes Incorporated DMN1 Series series groups 10 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. Every variant in the range shares a common FET feature of -, FET type of N-Channel and mounting type of Surface Mount. Variants differ by case, current - continuous drain (Id) @ 25°C and drain to source voltage, so you can match the exact case your application requires using the selection guide below. All listed Diodes Incorporated DMN1 Series part numbers are active and orderable.

Select a variant by

Case: 3-XFDFN · 4-XFBGA, WLBGA · 8-PowerVDFN · SOT-23-6 Thin, TSOT-23-6 · TO-236-3, SC-59, SOT-23-3 · TO-252-3, DPak (2 Leads + Tab), SC-63 · TO-261-4, TO-261AA
Current - continuous drain (Id) @ 25°C: 1.4A (Ta) · 2A (Ta), 7.1A (Tc) · 2.6A (Ta) · 2.7A (Ta) · 3.2A (Ta) · 3.8A (Ta) · 12A (Tc) · 17A (Tc) · 18A (Tc) · 500mA (Ta)
Drain to source voltage: 8 V · 12 V · 100 V · 150 V
Drive voltage (Max rds on, min rds on): 1.2V, 4.5V · 1.5V, 4.5V · 4.5V, 10V · 5V, 10V · 6V, 10V
Gate charge (Qg) (Max) @ vgs: 0.96 nC @ 4.5 V · 4.8 nC @ 4.5 V · 8.3 nC @ 10 V · 8.7 nC @ 10 V · 9.7 nC @ 10 V · 10.6 nC @ 10 V · 15 nC @ 4.5 V · 25.2 nC @ 10 V
Input capacitance (Ciss) (Max) @ vds: 60 pF @ 10 V · 375 pF @ 10 V · 401 pF @ 25 V · 405 pF @ 25 V · 549 pF @ 50 V · 908 pF @ 6 V · 1167 pF @ 25 V · 1172 pF @ 50 V
Operating temperature: -55°C ~ 150°C (TJ) · -55°C~150°C(TJ)
Package: Tape & Reel (TR) Cut Tape (CT) · Tape & Reel (TR); Cut Tape (CT)

Variant comparison

Parameter	DMN1045UFR4-7	DMN1054UCB4-7	DMN10H099SK3-13	DMN10H100SK3-13	DMN10H120SFG-7	DMN10H170SK3-13
Case	3-XFDFN	4-XFBGA, WLBGA	TO-252-3, DPak (2 Leads + Tab), SC-63	TO-252-3, DPak (2 Leads + Tab), SC-63	8-PowerVDFN	TO-252-3, DPak (2 Leads + Tab), SC-63
Current - continuous drain (Id) @ 25°C	3.2A (Ta)	2.7A (Ta)	17A (Tc)	18A (Tc)	3.8A (Ta)	12A (Tc)
Drain to source voltage	12 V	8 V	100 V	100 V	100 V	100 V
Drive voltage (Max rds on, min rds on)	1.5V, 4.5V	1.2V, 4.5V	6V, 10V	4.5V, 10V	6V, 10V	4.5V, 10V
Gate charge (Qg) (Max) @ vgs	4.8 nC @ 4.5 V	15 nC @ 4.5 V	25.2 nC @ 10 V	25.2 nC @ 10 V	10.6 nC @ 10 V	9.7 nC @ 10 V
Input capacitance (Ciss) (Max) @ vds	375 pF @ 10 V	908 pF @ 6 V	1172 pF @ 50 V	1172 pF @ 50 V	549 pF @ 50 V	1167 pF @ 25 V
Operating temperature	-55°C ~ 150°C (TJ)	-55°C ~ 150°C (TJ)	-55°C ~ 150°C (TJ)	-55°C ~ 150°C (TJ)	-55°C ~ 150°C (TJ)	-55°C ~ 150°C (TJ)
Package	Tape & Reel (TR) Cut Tape (CT)	Tape & Reel (TR) Cut Tape (CT)	Tape & Reel (TR) Cut Tape (CT)	Tape & Reel (TR) Cut Tape (CT)	Tape & Reel (TR) Cut Tape (CT)	Tape & Reel (TR) Cut Tape (CT)

Shared specifications

FET feature: -
FET type: N-Channel
Mounting type: Surface Mount
Technology: MOSFET (Metal Oxide)

Request a quote on any Diodes Incorporated DMN1 Series part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.

Frequently asked questions

How do the Diodes Incorporated Diodes Incorporated DMN1 Series variants differ?: Diodes Incorporated DMN1 Series part numbers differ by case, current - continuous drain (Id) @ 25°C, drain to source voltage and drive voltage (Max rds on, min rds on). Use the selection guide above to pick by case.
How many Diodes Incorporated Diodes Incorporated DMN1 Series part numbers are listed?: 10 Diodes Incorporated Diodes Incorporated DMN1 Series part numbers are listed, each with specifications and a datasheet where available.
How do I get pricing and lead time for Diodes Incorporated Diodes Incorporated DMN1 Series?: Request a quote (RFQ) for any Diodes Incorporated DMN1 Series part number and we confirm price, availability and lead time per line — including end-of-life and hard-to-find variants.
