DMC2004DWK-7
Diodes Incorporated
Tape & Reel (TR) Cut Tape (CT)-65°C ~ 150°C (TJ)N and P-Channel
Ref. price$0.4900
Lead time on requestGet quote ›
Diodes Incorporated DMC2 Series
15 variants · Diodes Incorporated
About the Diodes Incorporated Diodes Incorporated DMC2 Series series
The Diodes Incorporated Diodes Incorporated DMC2 Series series groups 15 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. Every variant in the range shares a common mounting type of Surface Mount, package of Tape & Reel (TR) Cut Tape (CT) and technology of MOSFET (Metal Oxide). Variants differ by case, configuration and current - continuous drain (Id) @ 25°C, so you can match the exact case your application requires using the selection guide below. All listed Diodes Incorporated DMC2 Series part numbers are active and orderable.
Select a variant by
- Case
- 6-SMD, No Lead · 6-TSSOP, SC-88, SOT-363 · 6-UDFN Exposed Pad · 8-SOIC (0.154\", 3.90mm Width) · SOT-23-6 · SOT-23-6 Thin, TSOT-23-6 · SOT-563, SOT-666
- Configuration
- N and P-Channel · N and P-Channel Complementary
- Current - continuous drain (Id) @ 25°C
- 1.03A, 700mA · 1.1A (Ta), 800mA (Ta) · 1.34A (Ta), 1.14A (Ta) · 1.34A, 1.14A · 4.6A (Ta), 3.2A (Ta) · 4.7A, 3.2A · 7.8A, 6.3A · 500mA, 3.9A · 540mA, 430mA · 750mA (Ta), 600mA (Ta) · 750mA, 600mA
- Drain to source voltage
- 20V · 25V, 12V
- FET feature
- - · Logic Level Gate
- Gate charge (Qg) (Max) @ vgs
- - · 0.5nC @ 4.5V · 0.6nC @ 4.5V, 0.7nC @ 4.5V · 0.74nC @ 4.5V · 0.74nC @ 4.5V, 0.62nC @ 4.5V · 0.9nC @ 10V · 3.6nC @ 4.5V, 5.9nC @ 4.5V · 11.6nC @ 4.5V · 15nC @ 8V
- Input capacitance (Ciss) (Max) @ vds
- 27.6pF @ 10V · 37.1pF @ 10V · 42pF @ 16V, 49pF @ 16V · 60.67pF @ 16V · 60.67pF @ 16V, 59.76pF @ 16V · 150pF @ 16V · 369pF @ 10V, 440pF @ 10V · 713pF @ 10V · 1149pF @ 10V
- Operating temperature
- -65°C ~ 150°C (TJ) · -55°C ~ 150°C (TJ)
Variant comparison
| Parameter | DMC2004DWK-7 | DMC2004LPK-7 | DMC2020USD-13 | DMC2041UFDB-7 | DMC2053UVT-7 | DMC2400UV-7 |
|---|---|---|---|---|---|---|
| Case | 6-TSSOP, SC-88, SOT-363 | 6-SMD, No Lead | 8-SOIC (0.154\", 3.90mm Width) | 6-UDFN Exposed Pad | SOT-23-6 Thin, TSOT-23-6 | SOT-563, SOT-666 |
| Configuration | N and P-Channel | N and P-Channel | N and P-Channel | N and P-Channel | N and P-Channel Complementary | N and P-Channel |
| Current - continuous drain (Id) @ 25°C | 540mA, 430mA | 750mA, 600mA | 7.8A, 6.3A | 4.7A, 3.2A | 4.6A (Ta), 3.2A (Ta) | 1.03A, 700mA |
| Drain to source voltage | 20V | 20V | 20V | 20V | 20V | 20V |
| FET feature | Logic Level Gate | Logic Level Gate | Logic Level Gate | - | - | Logic Level Gate |
| Gate charge (Qg) (Max) @ vgs | - | - | 11.6nC @ 4.5V | 15nC @ 8V | 3.6nC @ 4.5V, 5.9nC @ 4.5V | 0.5nC @ 4.5V |
| Input capacitance (Ciss) (Max) @ vds | 150pF @ 16V | 150pF @ 16V | 1149pF @ 10V | 713pF @ 10V | 369pF @ 10V, 440pF @ 10V | 37.1pF @ 10V |
| Operating temperature | -65°C ~ 150°C (TJ) | -65°C ~ 150°C (TJ) | -55°C ~ 150°C (TJ) | -55°C ~ 150°C (TJ) | -55°C ~ 150°C (TJ) | -55°C ~ 150°C (TJ) |
Shared specifications
- Mounting type
- Surface Mount
- Package
- Tape & Reel (TR) Cut Tape (CT)
- Technology
- MOSFET (Metal Oxide)
