BAT54-7-F
Diodes Incorporated
Tape & Reel (TR); Cut Tape (CT)Small Signal =< 200mA (Io), Any SpeedSchottky
Ref. price$0.1500
Lead time on requestGet quote ›
Diodes Incorporated BAT54 Series
17 variants · Diodes Incorporated
About the Diodes Incorporated Diodes Incorporated BAT54 Series series
The Diodes Incorporated Diodes Incorporated BAT54 Series series groups 17 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. Every variant in the range shares a common mounting type of Surface Mount, speed of Small Signal =< 200mA (Io), Any Speed and voltage - DC reverse (Vr) of 30 V. Variants differ by case, current - reverse leakage @ vr and operating temperature - junction, so you can match the exact case your application requires using the selection guide below. All listed Diodes Incorporated BAT54 Series part numbers are active and orderable.
Select a variant by
- Case
- 6-TSSOP, SC-88, SOT-363 · 0402 (1006 Metric) · SC-70, SOT-323 · SOT-523 · TO-236-3, SC-59, SOT-23-3
- Current - reverse leakage @ vr
- 2 µA @ 25 V · 4 µA @ 25 V
- Operating temperature - junction
- -65°C ~ 125°C · -65°C ~ 150°C · -65°C~150°C · 125°C (Max) · 125°C(Max)
- Package
- Tape & Reel (TR) Cut Tape (CT) · Tape & Reel (TR); Cut Tape (CT)
- Voltage - forward (Vf) (Max) @ if
- 1 V @ 100 mA · 800 mV @ 100 mA
- Diode configuration
- 1 Pair Common Anode · 1 Pair Common Cathode · 1 Pair Series Connection · 2 Pair Series Connection
Variant comparison
| Parameter | BAT54-7-F | BAT54AWQ-7-F | BAT54CTA | BAT54LP-7B | BAT54S-7-F | BAT54SDW-7-F |
|---|---|---|---|---|---|---|
| Case | TO-236-3, SC-59, SOT-23-3 | SC-70, SOT-323 | TO-236-3, SC-59, SOT-23-3 | 0402 (1006 Metric) | TO-236-3, SC-59, SOT-23-3 | 6-TSSOP, SC-88, SOT-363 |
| Current - reverse leakage @ vr | 2 µA @ 25 V | 2 µA @ 25 V | 4 µA @ 25 V | 2 µA @ 25 V | 2 µA @ 25 V | 2 µA @ 25 V |
| Operating temperature - junction | -65°C~150°C | -65°C ~ 125°C | 125°C (Max) | -65°C ~ 125°C | -65°C~150°C | -65°C ~ 125°C |
| Package | Tape & Reel (TR); Cut Tape (CT) | Tape & Reel (TR) Cut Tape (CT) | Tape & Reel (TR) Cut Tape (CT) | Tape & Reel (TR) Cut Tape (CT) | Tape & Reel (TR); Cut Tape (CT) | Tape & Reel (TR) Cut Tape (CT) |
| Voltage - forward (Vf) (Max) @ if | 800 mV @ 100 mA | 1 V @ 100 mA | 1 V @ 100 mA | 1 V @ 100 mA | 800 mV @ 100 mA | 1 V @ 100 mA |
| Diode configuration | — | 1 Pair Common Anode | 1 Pair Common Cathode | — | 1 Pair Series Connection | 2 Pair Series Connection |
Shared specifications
- Mounting type
- Surface Mount
- Speed
- Small Signal =< 200mA (Io), Any Speed
- Voltage - DC reverse (Vr)
- 30 V
Request a quote on any Diodes Incorporated BAT54 Series part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.
Frequently asked questions
- How do the Diodes Incorporated Diodes Incorporated BAT54 Series variants differ?
- Diodes Incorporated BAT54 Series part numbers differ by case, current - reverse leakage @ vr, operating temperature - junction and package. Use the selection guide above to pick by case.
- How many Diodes Incorporated Diodes Incorporated BAT54 Series part numbers are listed?
- 17 Diodes Incorporated Diodes Incorporated BAT54 Series part numbers are listed, each with specifications and a datasheet where available.
- How do I get pricing and lead time for Diodes Incorporated Diodes Incorporated BAT54 Series?
- Request a quote (RFQ) for any Diodes Incorporated BAT54 Series part number and we confirm price, availability and lead time per line — including end-of-life and hard-to-find variants.
