BAS16HLP-7
Diodes Incorporated
Tape & Reel (TR) Cut Tape (CT)Fast Recovery =< 500ns, > 200mA (Io)Standard
Ref. price$0.3600
Lead time on requestGet quote
Diodes Incorporated BAS16 Series
25 variants · Diodes Incorporated
About the Diodes Incorporated BAS16 Series
The Diodes Incorporated BAS16 Series series groups 25 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. The listed variants share a common mounting of Surface Mount and reverse recovery time of 4 ns. Variants differ by case, current - reverse leakage @ vr and operating temperature - junction, so you can match the exact case your application requires using the selection guide below. The range mixes active and legacy part numbers, so you can source both current Diodes Incorporated BAS16 Series variants and discontinued ones from a single page.
Select a variant by
- Case
- 6-TSSOP, SC-88, SOT-363 · 0402 (1006 Metric) · SC-70, SOT-323 · SOT-523 · SOT-563, SOT-666 · TO-236-3, SC-59, SOT-23-3
- Current - reverse leakage @ vr
- 1 µA @ 75 V · 2 µA @ 75 V · 500 nA @ 80 V
- Operating temperature - junction
- -65°C ~ 150°C · -65°C~150°C · -55°C ~ 150°C · -55°C~150°C
- Package
- Tape & Reel (TR) Cut Tape (CT) · Tape & Reel (TR); Cut Tape (CT)
- Speed
- Fast Recovery =< 500ns, > 200mA (Io) · Small Signal =< 200mA (Io), Any Speed
- Voltage - DC reverse (Vr)
- 75 V · 85 V · 100 V
- Voltage - forward (Vf) (Max) @ if
- 1 V @ 50 mA · 1.25 V @ 150 mA
Shared specifications
- Mounting
- Surface Mount
- Reverse recovery time
- 4 ns
Variant comparison
| Parameter | BAS16HLP-7 | BAS16HLPQ-7B | BAS16HTWQ-13 | BAS16LP-7 | BAS16T-7-F | BAS16TW-7-F |
|---|---|---|---|---|---|---|
| Case | 0402 (1006 Metric) | 0402 (1006 Metric) | 6-TSSOP, SC-88, SOT-363 | 0402 (1006 Metric) | SOT-523 | 6-TSSOP, SC-88, SOT-363 |
| Current - reverse leakage @ vr | 500 nA @ 80 V | 500 nA @ 80 V | 500 nA @ 80 V | 1 µA @ 75 V | 2 µA @ 75 V | 1 µA @ 75 V |
| Operating temperature - junction | -65°C ~ 150°C | -65°C~150°C | -65°C ~ 150°C | -65°C ~ 150°C | -65°C ~ 150°C | -65°C~150°C |
| Package | Tape & Reel (TR) Cut Tape (CT) | Tape & Reel (TR); Cut Tape (CT) | Tape & Reel (TR) Cut Tape (CT) | Tape & Reel (TR) Cut Tape (CT) | Tape & Reel (TR) Cut Tape (CT) | Tape & Reel (TR); Cut Tape (CT) |
| Speed | Fast Recovery =< 500ns, > 200mA (Io) | Fast Recovery =< 500ns, > 200mA (Io) | Small Signal =< 200mA (Io), Any Speed | Small Signal =< 200mA (Io), Any Speed | Small Signal =< 200mA (Io), Any Speed | Small Signal =< 200mA (Io), Any Speed |
| Voltage - DC reverse (Vr) | 100 V | 100 V | 100 V | 75 V | 85 V | 75 V |
| Voltage - forward (Vf) (Max) @ if | 1.25 V @ 150 mA | 1.25 V @ 150 mA | 1.25 V @ 150 mA | 1.25 V @ 150 mA | 1 V @ 50 mA | 1.25 V @ 150 mA |
Request a quote on any Diodes Incorporated BAS16 Series part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.
