How many Diodes Incorporated Diodes Incorporated BAS1 Series part numbers are listed?

11 Diodes Incorporated Diodes Incorporated BAS1 Series part numbers are listed, each with specifications and a datasheet where available.

Diodes Incorporated BAS1 Series

Q: How do the Diodes Incorporated Diodes Incorporated BAS1 Series variants differ?

Diodes Incorporated BAS1 Series part numbers differ by case, current - reverse leakage @ vr, operating temperature - junction and package. Use the selection guide above to pick by case.

Q: How do I get pricing and lead time for Diodes Incorporated Diodes Incorporated BAS1 Series?

Request a quote (RFQ) for any Diodes Incorporated BAS1 Series part number and we confirm price, availability and lead time per line — including end-of-life and hard-to-find variants.

11 variants · Diodes Incorporated

About the Diodes Incorporated Diodes Incorporated BAS1 Series series

The Diodes Incorporated Diodes Incorporated BAS1 Series series groups 11 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. The listed variants share a common mounting type of Surface Mount, reverse recovery time of 4 ns and speed of Small Signal =< 200mA (Io), Any Speed. Variants differ by case, current - reverse leakage @ vr and operating temperature - junction, so you can match the exact case your application requires using the selection guide below.

Select a variant by

Case: 6-TSSOP, SC-88, SOT-363 · SC-70, SOT-323 · SOT-523 · SOT-563, SOT-666
Current - reverse leakage @ vr: 1 µA @ 75 V · 2 µA @ 75 V · 500 nA @ 80 V
Operating temperature - junction: -65°C ~ 150°C · -65°C~150°C · -55°C ~ 150°C · -55°C~150°C
Package: Tape & Reel (TR) Cut Tape (CT) · Tape & Reel (TR); Cut Tape (CT)
Voltage - DC reverse (Vr): 75 V · 85 V · 100 V
Voltage - forward (Vf) (Max) @ if: 1 V @ 50 mA · 1.25 V @ 150 mA
Current - average rectified (Io) (per diode): 150mA · 200mA (DC)
Capacitance @ vr, f: 1.5pF @ 0V, 1MHz · 2pF @ 0V, 1MHz

Variant comparison

Parameter	BAS16HTWQ-13	BAS16T-7-F	BAS16TW-7-F	BAS16TWQ-13R-F	BAS16VA-7	BAS16VV-7
Case	6-TSSOP, SC-88, SOT-363	SOT-523	6-TSSOP, SC-88, SOT-363	6-TSSOP, SC-88, SOT-363	SOT-563, SOT-666	SOT-563, SOT-666
Current - reverse leakage @ vr	500 nA @ 80 V	2 µA @ 75 V	1 µA @ 75 V	1 µA @ 75 V	500 nA @ 80 V	500 nA @ 80 V
Operating temperature - junction	-65°C ~ 150°C	-65°C ~ 150°C	-65°C~150°C	-65°C ~ 150°C	-55°C ~ 150°C	-55°C~150°C
Package	Tape & Reel (TR) Cut Tape (CT)	Tape & Reel (TR) Cut Tape (CT)	Tape & Reel (TR); Cut Tape (CT)	Tape & Reel (TR) Cut Tape (CT)	Tape & Reel (TR) Cut Tape (CT)	Tape & Reel (TR); Cut Tape (CT)
Voltage - DC reverse (Vr)	100 V	85 V	75 V	100 V	100 V	100 V
Voltage - forward (Vf) (Max) @ if	1.25 V @ 150 mA	1 V @ 50 mA	1.25 V @ 150 mA	1.25 V @ 150 mA	1.25 V @ 150 mA	1.25 V @ 150 mA
Current - average rectified (Io) (per diode)	200mA (DC)	—	150mA	150mA	200mA (DC)	200mA (DC)
Capacitance @ vr, f	—	1.5pF @ 0V, 1MHz	—	—	—	—

Shared specifications

Mounting type: Surface Mount
Reverse recovery time: 4 ns
Speed: Small Signal =< 200mA (Io), Any Speed

Request a quote on any Diodes Incorporated BAS1 Series part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.

Frequently asked questions

How do the Diodes Incorporated Diodes Incorporated BAS1 Series variants differ?: Diodes Incorporated BAS1 Series part numbers differ by case, current - reverse leakage @ vr, operating temperature - junction and package. Use the selection guide above to pick by case.
How many Diodes Incorporated Diodes Incorporated BAS1 Series part numbers are listed?: 11 Diodes Incorporated Diodes Incorporated BAS1 Series part numbers are listed, each with specifications and a datasheet where available.
How do I get pricing and lead time for Diodes Incorporated Diodes Incorporated BAS1 Series?: Request a quote (RFQ) for any Diodes Incorporated BAS1 Series part number and we confirm price, availability and lead time per line — including end-of-life and hard-to-find variants.
