HCPL-0201
Broadcom Limited
4.5V ~ 20VTube-40°C~85°C
Ref. price$5.9200
Lead time on requestGet quote ›
Broadcom Limited HCPL Series
60 variants · Broadcom Limited
About the Broadcom Limited Broadcom Limited HCPL Series series
The Broadcom Limited Broadcom Limited HCPL Series series groups 60 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. The listed variants share a common case of 8-SOIC (0.154\", 3.90mm Width), input type of DC and mounting type of Surface Mount. Variants differ by common mode transient immunity, current - DC forward (If) and current - output (Channel), so you can match the exact common mode transient immunity your application requires using the selection guide below.
Select a variant by
- Common mode transient immunity
- 1kV/µs · 5kV/µs · 5kV/µs, 10kV/µs · 10kV/µs · 15kV/µs
- Current - DC forward (If)
- 10mA · 15mA · 20mA · 25mA
- Current - output (Channel)
- 15 mA · 25 mA · 50 mA
- Data rate
- - · 5MBd · 10MBd
- Inputs - side 1/Side 2
- 1/0 · 2/0
- Number of channels
- 1 · 2
- Operating temperature
- -40°C ~ 85°C · -40°C~85°C · -40°C~100°C
- Output type
- Open Collector, Schottky Clamped · Push-Pull, Totem Pole
Variant comparison
| Parameter | HCPL-0201 | HCPL-0201-000E | HCPL-0211-000E | HCPL-0211-500E | HCPL-0466-000E | HCPL-0600 |
|---|---|---|---|---|---|---|
| Common mode transient immunity | 1kV/µs | 5kV/µs, 10kV/µs | 5kV/µs, 10kV/µs | 5kV/µs, 10kV/µs | 15kV/µs | 5kV/µs |
| Current - DC forward (If) | 10mA | 10mA | 10mA | 10mA | 25mA | 20mA |
| Current - output (Channel) | 25 mA | 25 mA | 25 mA | 25 mA | 15 mA | 50 mA |
| Data rate | 5MBd | 5MBd | 5MBd | 5MBd | - | 10MBd |
| Inputs - side 1/Side 2 | 1/0 | 1/0 | 1/0 | 1/0 | 1/0 | 1/0 |
| Number of channels | 1 | 1 | 1 | 1 | 1 | 1 |
| Operating temperature | -40°C~85°C | -40°C ~ 85°C | -40°C ~ 85°C | -40°C~85°C | -40°C~100°C | -40°C~85°C |
| Output type | Push-Pull, Totem Pole | Push-Pull, Totem Pole | Push-Pull, Totem Pole | Push-Pull, Totem Pole | Open Collector, Schottky Clamped | Open Collector, Schottky Clamped |
Shared specifications
- Case
- 8-SOIC (0.154\", 3.90mm Width)
- Input type
- DC
- Mounting type
- Surface Mount
- Voltage - isolation
- 3750Vrms
