Bourns Inc. SRR1280-4R5Y
MPNSRR1280-4R5Y
Active
$1.1800Ref. price · indicative, final on quote
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Jul 2026
Specifications
| Parameter | Value |
|---|---|
| Type | Drum Core, Wirewound |
| Series | SRR1280 |
| Mounting | Surface Mount |
| Current rating | 8.5 A |
| Current - saturation | 9A |
| Frequency - self resonant | 34MHz |
| Inductance frequency - test | 100 kHz |
| Operating temperature | -40°C ~ 125°C |
| Material - core | Ferrite |
| Size (Dimension) | 0.492\" L x 0.492\" W (12.50mm x 12.50mm) |
| Height - seated | 0.315\" (8.00mm) |
| Package | Tape & Reel (TR) Cut Tape (CT) |
| Q @ freq | 20 @ 7.96MHz |
| Shielding | Shielded |
| Tolerance | ±30% |
| Inductance | 4.5 µH |
| Case | Nonstandard |
| DC resistance | 13.5mOhm Max |
