Bourns Inc. SRP1205-R60Y
MPNSRP1205-R60Y
Obsolete
Independent supplier — new & surplus stockAuthenticity-screened · ESD-safe packingListing updated Jul 2026
Specifications
| Parameter | Value |
|---|---|
| Type | Drum Core, Wirewound |
| Series | SRP1205 |
| Mounting | Surface Mount |
| Current rating | 16 A |
| Current - saturation | 27A |
| Frequency - self resonant | 95MHz |
| Inductance frequency - test | 100 kHz |
| Operating temperature | -55°C~150°C |
| Material - core | Ferrite |
| Size (Dimension) | 0.492\" L x 0.492\" W (12.50mm x 12.50mm) |
| Height - seated | 0.197\" (5.00mm) |
| Package | Tape & Reel (TR) |
| Shielding | Shielded |
| Tolerance | ±25% |
| Inductance | 600 nH |
| Case | Nonstandard |
| DC resistance | 2.5mOhm Max |
