MAX4378HAUD+ Current Sense Amplifier, 14-TSSOP, 2 MHz

MPNMAX4378HAUD+
End of Life

Maxim Integrated MAX4378HAUD+, quad current-sense amplifier, 14-TSSOP, 3 V to 28 V supply, 2 MHz bandwidth, 10 V/µs slew rate, -40°C to 125°C, Tube.

$6.14Ref. price · indicative, final on quote
MAX4378HAUD+ datasheet
Packaging14-TSSOP (0.173", 4.40mm Width)
StockContact for availability
MOQ1 pcs
  • 100% new & originalTraceable channels only — no refurbs, no pulls, no remarked parts.
  • Date & lot codes on quoteStated per line before you commit; label photos on request.
  • MSL-compliant ESD packingMoisture-sealed bags with indicator cards; reels photo-verified.
  • PayPal buyer protectionPay by T/T, PayPal or Payoneer — card payments covered end to end.

Specifications

MAX4378HAUD+ Technical Specifications
ParameterValue
Mounting typeSurface Mount
Amplifier typeCurrent Sense
Voltage - supply span28 V
Current - supply1mA (x4 Channels)
Current - input bias120 µA
Operating temperature-40°C ~ 125°C
-3db bandwidth2 MHz
PackageTube
Slew rate10V/µs
Case14-TSSOP (0.173\", 4.40mm Width)
Number of circuits4

Product details

Quad current-sense amplifier in a compact 14-TSSOP

The MAX4378HAUD+ is a quad current-sense amplifier in a 14-TSSOP package. It monitors current on up to four independent rails. Supply span is 3 V to 28 V, bandwidth 2 MHz, slew rate 10 V/µs, temperature range -40°C to 125°C.

Supply voltage range and power budget

Minimum supply is 3 V, maximum 28 V. Each channel draws 1 mA supply current, total 4 mA.

Bandwidth and response time

The 2 MHz -3 dB bandwidth supports current monitoring in switching regulators switching at a few hundred kilohertz, where the sense amplifier must track the inductor current waveform. The 10 V/µs slew rate ensures the output can swing quickly when a fault current appears, which matters for overcurrent detection circuits that need to trigger a shutdown within a few microseconds.

Frequently asked questions

Is the MAX4378HAUD+ available in tape and reel?

No, the listed package is Tube, not tape and reel. If your assembly line requires reel packaging, confirm compatibility or check for a T-suffix variant.

What is the MAX4378HAUD+ bandwidth?

The -3 dB bandwidth is 2 MHz, with a slew rate of 10 V/µs.
