MAX20337ENT+T Analog Switch, 330mOhm, 220MHz, 6-WLP

MPNMAX20337ENT+T
End of Life

Maxim Integrated Beyond-the-Rails™ MAX20337ENT+T, SPST-NO analog switch, 330mOhm on-resistance, 220MHz -3dB bandwidth, 1.6V-5.5V single supply, 6-WLP (1.31x0.83mm), -40°C to 85°C.

$1.97Ref. price · indicative, final on quote
MAX20337ENT+T datasheet
Packaging6-XFBGA, WLBGA
StockContact for availability
MOQ1 pcs
  • 100% new & originalTraceable channels only — no refurbs, no pulls, no remarked parts.
  • Date & lot codes on quoteStated per line before you commit; label photos on request.
  • MSL-compliant ESD packingMoisture-sealed bags with indicator cards; reels photo-verified.
  • PayPal buyer protectionPay by T/T, PayPal or Payoneer — card payments covered end to end.

Specifications

MAX20337ENT+T Technical Specifications
ParameterValue
SeriesBeyond-the-Rails™
Mounting typeSurface Mount
Voltage - supply, single (V+)1.6V ~ 5.5V
Current - leakage (IS(off))100nA
Operating temperature-40°C ~ 85°C (TA)
-3db bandwidth220MHz
PackageTape & Reel (TR); Cut Tape (CT)
Crosstalk-55dB @ 100kHz
Case6-XFBGA, WLBGA
Switch circuitSPST - NO
Number of circuits1
On-State resistance330mOhm
Switch time (Ton, toff)32.5ms, 8.8ms (Typ)
Multiplexer (Demultiplexer circuit)2:1
Channel-to-Channel matching (ΔRon)3mOhm
Channel capacitance (CS(off), CD(off))19pF

Product details

What this switch does and where it fits

The MAX20337ENT+T is a single-pole single-throw normally-open (SPST-NO) analog switch from Maxim Integrated's Beyond-the-Rails™ series. It routes one signal path through a 330 mOhm on-resistance with a 220 MHz -3 dB bandwidth.

Package and footprint reality

The part comes in a 6-bump wafer-level package (6-WLP) measuring 1.31 x 0.83 mm. That is a tiny footprint — roughly the size of a grain of rice — which saves board space but demands a controlled solder-paste stencil and a reflow profile compatible with WLP assembly. The package is surface-mount only, and the supply is available in Tape & Reel or Cut Tape. For a prototype run, the Cut Tape option lets you order a few pieces without committing to a full reel.

Lifecycle and sourcing posture

There is no end-of-life notice or last-time-buy window to track. No stock count or lead-time number is published here; submit an RFQ for a firm commitment.

Frequently asked questions

What is the on-resistance of MAX20337ENT+T?

The maximum on-resistance is 330 mOhm. That is the resistance between the source and drain terminals when the switch is turned on.

What is the difference between MAX20337ENT+T and MAX20336ENT+T?

The MAX20336ENT+T is a 2:1 multiplexer/demultiplexer, while the MAX20337ENT+T is a single SPST-NO switch. The MAX20336 routes one of two inputs to a common output; the MAX20337 simply opens or closes one signal path. Both share the same 330 mOhm on-resistance and 220 MHz bandwidth.
