Analog Devices MAX1501ZETE+ multi-chemistry battery charger IC, 1-3 series cells, programmable charge current up to 1.4A, over-voltage protection, 16-TQFN exposed pad package, -40°C to 85°C.
| Parameter | Value |
|---|---|
| Mounting type | Surface Mount |
| Voltage | 6.25V |
| Current - charging | Constant - Programmable |
| Charge current - max | 1.4A |
| Operating temperature | -40°C ~ 85°C (TA) |
| Package | Tube |
| Case | 16-WQFN Exposed Pad |
| Number of cells | 1 ~ 3 |
| Fault protection | Over Voltage |
| Battery chemistry | Multi-Chemistry |
The MAX1501ZETE+: It accepts a maximum supply voltage of 6.25 V and integrates over-voltage fault protection, making it suited for portable and handheld equipment where a single input rail powers the charge cycle.
The MAX1501ZETE+ supports multi-chemistry battery types — it is not limited to a single chemistry, so it can charge Li-Ion, Li-Poly, NiMH, or NiCd cells depending on the charge algorithm implemented by the host controller.
The MAX1501ZETE+ supports charging 1 to 3 series-connected cells. The pinout is defined in the datasheet for the 16-TQFN (5x5) package; the number of cells is typically set via external resistor dividers on the CELLS pin.
For a different cell count or charge current, consider other members of the MAX1501 family, but verify pinout and package compatibility against the BOM.
