MAX13235EETP+ RS232 Transceiver, 3Mbps, 2/2, 20-TQFN

MPNMAX13235EETP+
End of Life

Analog Devices MAX13235EETP+ RS232 transceiver, full duplex, 2/2 drivers/receivers, 3Mbps data rate, 20-TQFN (5x5) exposed pad, surface mount, 3V to 5.5V supply, -40°C to +85°C.

$11.8Ref. price · indicative, final on quote
Packaging20-WQFN Exposed Pad
StockContact for availability
Lead timeIn Stock wk
MOQ1 pcs
  • 100% new & originalTraceable channels only — no refurbs, no pulls, no remarked parts.
  • Date & lot codes on quoteStated per line before you commit; label photos on request.
  • MSL-compliant ESD packingMoisture-sealed bags with indicator cards; reels photo-verified.
  • PayPal buyer protectionPay by T/T, PayPal or Payoneer — card payments covered end to end.

Specifications

MAX13235EETP+ Technical Specifications
ParameterValue
TypeTransceiver
Mounting typeSurface Mount
Voltage3V ~ 5.5V
ProtocolRS232
Operating temperature-40°C ~ 85°C
DuplexFull
PackageTube
Data rate3Mbps
Case20-WQFN Exposed Pad
Receiver hysteresis500 mV
Number of drivers (Receivers)2/2

Product details

RS232 transceiver for 3Mbps serial links

The MAX13235EETP+: It handles serial data rates up to 3 Mbps, making it suitable for high-speed point-to-point or multi-drop RS232 links where legacy 115 kbps parts fall short.

Housed in a 20-WQFN with exposed pad (supplier package 20-TQFN, 5x5 mm), the part requires a solder-paste stencil that covers the thermal pad for proper heat transfer. The pad must be connected to the ground plane with multiple vias to achieve the datasheet thermal resistance.

Lifecycle and compliance status

Availability is confirmed per RFQ; lead times and pricing vary with market conditions and are quoted at order time.

Frequently asked questions

What is the data rate and driver/receiver configuration of MAX13235EETP+?

It supports 3 Mbps full-duplex RS232 communication with two drivers and two receivers (2/2). The 500 mV receiver hysteresis helps reject noise on longer cable runs.
