LTC6954IUFF-4#PBF Clock Buffer 1:3 1.4GHz 36-QFN - Analog

MPNLTC6954IUFF-4#PBF
End of Life

Analog Devices LTC6954IUFF-4#PBF, Fanout Buffer (Distribution), Divider, 1 circuit, 1:3 ratio, 1.4 GHz max, LVCMOS/LVDS/LVPECL input, LVCMOS/LVDS output, 36-WFQFN Exposed Pad, -40°C to 105°C.

$19.73Ref. price · indicative, final on quote
LTC6954IUFF-4#PBF datasheet
Packaging36-WFQFN Exposed Pad
StockContact for availability
MOQ1 pcs
  • 100% new & originalTraceable channels only — no refurbs, no pulls, no remarked parts.
  • Date & lot codes on quoteStated per line before you commit; label photos on request.
  • MSL-compliant ESD packingMoisture-sealed bags with indicator cards; reels photo-verified.
  • PayPal buyer protectionPay by T/T, PayPal or Payoneer — card payments covered end to end.

Specifications

LTC6954IUFF-4#PBF Technical Specifications
ParameterValue
TypeFanout Buffer (Distribution), Divider
Mounting typeSurface Mount
Voltage3.15V ~ 3.45V
Frequency1.4 GHz
Operating temperature-40°C ~ 105°C
InputLVCMOS, LVDS, LVPECL
OutputLVCMOS, LVDS
PackageTube
Case36-WFQFN Exposed Pad
Number of circuits1
Ratio - Input:Output1:3
Differential - Input:OutputYes/Yes

Product details

What this clock buffer does at 1.4 GHz

The LTC6954IUFF-4#PBF is a single-channel fanout buffer with an integrated divider, accepting LVCMOS, LVDS, or LVPECL inputs and delivering LVCMOS or LVDS outputs at a maximum frequency of 1.4 GHz. The 1:3 ratio means one input drives three output paths — useful for splitting a reference clock to multiple ADCs, FPGAs, or SerDes transceivers without adding jitter from a separate PLL.

Industrial temperature grade and supply rails

The supply voltage range is tight at 3.15V to 3.45V — plan a clean 3.3V rail with ±5% tolerance; a switching regulator with 50 mV ripple will eat into that margin.

Package and footprint for layout

Housed in a 36-WFQFN with exposed pad, 4 mm x 7 mm body. Surface-mount only; no through-hole option.

Active production — no EOL concern

For BOM planning, this line item is stable — no forced redesign or last-time buy horizon.

Frequently asked questions

Is LTC6954IUFF-4#PBF suitable for high-speed clock distribution?

Yes — the 1.4 GHz maximum frequency and differential input/output make it appropriate for distributing high-speed reference clocks to ADCs, DACs, or FPGAs. The 1:3 fanout keeps the signal path short and matched.

What is the difference between LTC6954IUFF-4#PBF and the LTC6957 variants?

The LTC6957 family (e.g., LTC6957IDD-2#PBF) is a fanout buffer only — no divider — with a maximum frequency of 300 MHz and a 1:2 ratio, versus the LTC6954's 1.4 GHz and 1:3 ratio with divider. The LTC6957 also tops out at 85°C, while the LTC6954IUFF-4#PBF extends to 105°C. These are not drop-in replacements; the LTC6954 is the higher-speed, wider-temperature option.
