Analog Devices AD9542BCPZ — Clock & Timing ICs

AD9542BCPZ Clock Synthesizer – Analog Devices, 2.415 GHz

MPNAD9542BCPZ
End of Life

Analog Devices AD9542BCPZ, Clock Synthesizer, PLL Yes, 2.415 GHz max, 4:5 input-to-output ratio, 2 circuits, 48-LFCSP (7x7) exposed pad, -40°C to 85°C

$20.31Ref. price · indicative, final on quote
Packaging48-WFQFN Exposed Pad, CSP
RoHSROHS3 Compliant
Independent supplier — new & surplus stockAuthenticity-screened · ESD-safe packingListing updated Aug 2026

Specifications

AD9542BCPZ specifications
ParameterValue
TypeClock Synthesizer
MountingSurface Mount
Voltage1.71V ~ 1.89V, 1.71V ~ 3.465V
Frequency2.415GHz
Operating temperature-40°C ~ 85°C
PLLYes
InputCMOS, Differential or Single-Ended, LVDS, LVPECL
OutputCML, CMOS, HCSL, LVDS or Single-Ended
PackageTray
Case48-WFQFN Exposed Pad, CSP
Divider (Multiplier)Yes/Yes
Number of circuits2
Ratio - Input:Output4:5
Differential - Input:OutputNo/Yes

Product details

What the AD9542BCPZ does on the board

The AD9542BCPZ is a dual-PLL clock synthesizer from Analog Devices that generates a clean, low-jitter output clock up to 2.415 GHz from a variety of input references — CMOS, differential, single-ended, LVDS, or LVPECL. Its 4:5 input-to-output ratio and two independent PLL circuits make it suited for multi-frequency clock trees in communications infrastructure, instrumentation, and data-converter clocking.

Parametric deep-dive: frequency, supply, and signal flexibility

The 2.415 GHz maximum output frequency covers RF and IF clock synthesis for ADCs, DACs, and mixers up into the low microwave band. The dual supply — a 1.71V–1.89V core rail and a separate 1.71V–3.465V I/O rail — lets the output buffers swing at the logic level of the downstream device without extra translation. Output options include CML, CMOS, HCSL, and LVDS, so the same part can drive a serializer, an FPGA reference clock, or a data converter sample clock.

Package and footprint: 48-LFCSP with exposed pad

The 48-LFCSP (7x7) package is a surface-mount, quad-flat no-lead with an exposed thermal pad.

Frequently asked questions

Does AD9542BCPZ support CML output?

Yes, the AD9542BCPZ output options include CML, along with CMOS, HCSL, and LVDS — covering the common interface standards for high-speed clock distribution.

What is the closest functional equivalent to AD9542BCPZ?

The AD9542BCPZ-REEL7 is the same silicon in tape-and-reel packaging — electrically identical. For a different feature set, the AD9544BCPZ-REEL7 is a clock synchronizer with 2.4 GHz max frequency and 4:10 input-to-output ratio, but without the divider/multiplier function.
