MAX485ESA+T
Analog Devices Inc./Maxim Integrated
Surface MountTape & Reel (TR) Cut Tape (CT)-40°C ~ 85°C
Ref. price$1.07896
Lead time on requestGet quote
Analog Devices Inc./Maxim Integrated MAX48 Interface Series
129 variants · Analog Devices Inc./Maxim Integrated
About the Analog Devices Inc./Maxim Integrated MAX48 Interface Series
The Analog Devices Inc./Maxim Integrated MAX48 Interface Series series groups 129 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. The listed variants share a common duplex of Half, number of drivers (Receivers) of 1/1 and protocol of RS422, RS485. Variants differ by case, data rate and mounting, so you can match the exact case your application requires using the selection guide below.
Select a variant by
- Case
- 8-DIP (0.300\", 7.62mm) · 8-SOIC (0.154\", 3.90mm Width) · 8-TSSOP, 8-MSOP (0.118\", 3.00mm Width)
- Data rate
- 2.5Mbps · 250kbps
- Mounting
- Surface Mount · Through Hole
- Operating temperature
- -40°C ~ 85°C · 0°C ~ 70°C · 0°C~70°C
- Package
- Tape & Reel (TR) Cut Tape (CT) · Tape & Reel (TR); Cut Tape (CT) · Tube
Shared specifications
- Duplex
- Half
- Number of drivers (Receivers)
- 1/1
- Protocol
- RS422, RS485
- Receiver hysteresis
- 70 mV
- Type
- Transceiver
- Voltage
- 4.75V ~ 5.25V
Variant comparison
| Parameter | MAX481CSA+ | MAX481CUA+ | MAX481ECPA+ | MAX481ECSA+ | MAX481ECSA+T | MAX481ESA+ |
|---|---|---|---|---|---|---|
| Case | 8-SOIC (0.154\", 3.90mm Width) | 8-TSSOP, 8-MSOP (0.118\", 3.00mm Width) | 8-DIP (0.300\", 7.62mm) | 8-SOIC (0.154\", 3.90mm Width) | 8-SOIC (0.154\", 3.90mm Width) | 8-SOIC (0.154\", 3.90mm Width) |
| Data rate | 2.5Mbps | 2.5Mbps | 2.5Mbps | 2.5Mbps | 2.5Mbps | 2.5Mbps |
| Mounting | Surface Mount | Surface Mount | Through Hole | Surface Mount | Surface Mount | Surface Mount |
| Operating temperature | 0°C ~ 70°C | 0°C ~ 70°C | 0°C~70°C | 0°C ~ 70°C | 0°C~70°C | -40°C ~ 85°C |
| Package | Tube | Tube | Tube | Tube | Tape & Reel (TR); Cut Tape (CT) | Tube |
Request a quote on any Analog Devices Inc./Maxim Integrated MAX48 Interface Series part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.
