MAX3483AEASA+
Analog Devices Inc./Maxim Integrated
Surface MountTube-40°C ~ 125°C
Ref. price$5.8900
Lead time on requestGet quote
Analog Devices Inc./Maxim Integrated MAX3 Interface Series
21 variants · Analog Devices Inc./Maxim IntegratedAll Interface & Transceivers →
About the Analog Devices Inc./Maxim Integrated MAX3 Interface Series
The Analog Devices Inc./Maxim Integrated MAX3 Interface Series series groups 21 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. The listed variants share a common type of Transceiver. Variants differ by case, data rate and duplex, so you can match the exact case your application requires using the selection guide below.
Select a variant by
- Case
- 8-DIP (0.300\", 7.62mm) · 8-SOIC (0.154\", 3.90mm Width) · 16-SSOP (0.209\", 5.30mm Width)
- Data rate
- 10Mbps · 20Mbps · 120kbps · 250kbps
- Duplex
- Full · Half
- Mounting
- Surface Mount · Through Hole
- Number of drivers (Receivers)
- 1/1 · 2/2
- Operating temperature
- -40°C ~ 125°C · 0°C ~ 70°C · 0°C ~ 70°C (TA) · 0°C~70°C
- Package
- Bulk · Tape & Reel (TR) Cut Tape (CT) · Tube
- Protocol
- RS232 · RS422, RS485
Shared specifications
- Type
- Transceiver
Variant comparison
| Parameter | MAX3483AEASA+ | MAX3483AEASA+T | MAX3483CSA+ | MAX3485AEASA+ | MAX3485CPA+ | MAX3485CSA+ |
|---|---|---|---|---|---|---|
| Case | 8-SOIC (0.154\", 3.90mm Width) | 8-SOIC (0.154\", 3.90mm Width) | 8-SOIC (0.154\", 3.90mm Width) | 8-SOIC (0.154\", 3.90mm Width) | 8-DIP (0.300\", 7.62mm) | 8-SOIC (0.154\", 3.90mm Width) |
| Data rate | 250kbps | 250kbps | 250kbps | 20Mbps | 10Mbps | 10Mbps |
| Duplex | Half | Half | Half | Half | Half | Half |
| Mounting | Surface Mount | Surface Mount | Surface Mount | Surface Mount | Through Hole | Surface Mount |
| Number of drivers (Receivers) | 1/1 | 1/1 | 1/1 | 1/1 | 1/1 | 1/1 |
| Operating temperature | -40°C ~ 125°C | -40°C ~ 125°C | 0°C ~ 70°C | -40°C ~ 125°C | 0°C ~ 70°C | 0°C ~ 70°C |
| Package | Tube | Tape & Reel (TR) Cut Tape (CT) | Tube | Tube | Tube | Tube |
| Protocol | RS422, RS485 | RS422, RS485 | RS422, RS485 | RS422, RS485 | RS422, RS485 | RS422, RS485 |
Request a quote on any Analog Devices Inc./Maxim Integrated MAX3 Interface Series part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.
