Allegro MicroSystems ACS7 Series
111 variants · Allegro MicroSystems
About the Allegro MicroSystems Allegro MicroSystems ACS7 Series series
The Allegro MicroSystems Allegro MicroSystems ACS7 Series series groups 111 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. The listed variants share a common number of channels of 1, package of Tape & Reel (TR) Cut Tape (CT) and response time of 4µs. Variants differ by accuracy, case and current - sensing, so you can match the exact accuracy your application requires using the selection guide below.
Select a variant by
- Accuracy
- - · ±0.6% · ±0.8% · ±1% · ±6%
- Case
- 8-SOIC (0.154\", 3.90mm Width) · 12-PowerWFQFN · 16-SOIC (0.295\", 7.50mm Width)
- Current - sensing
- 5A · 10A · 20A · 30A · 45A · 50A · 65A
- Current - supply
- 12mA · 14mA
- For measuring
- AC/DC · DC
- Frequency
- 120kHz · DC ~ 120kHz
- Linearity
- ±1.5% · ±1%
- Mounting type
- Surface Mount · Surface Mount, Wettable Flank
Variant comparison
| Parameter | ACS71240KEXBLT-010B3 | ACS71240KEXBLT-030B3 | ACS71240KEXBLT-030B5 | ACS71240KEXBLT-050U5 | ACS71240LLCBTR-030B3 | ACS71240LLCBTR-045B5 |
|---|---|---|---|---|---|---|
| Accuracy | ±6% | ±6% | - | ±6% | ±6% | ±6% |
| Case | 12-PowerWFQFN | 12-PowerWFQFN | 12-PowerWFQFN | 12-PowerWFQFN | 8-SOIC (0.154\", 3.90mm Width) | 8-SOIC (0.154\", 3.90mm Width) |
| Current - sensing | 10A | 30A | 30A | 50A | 30A | 45A |
| Current - supply | 12mA | 12mA | 12mA | 12mA | 12mA | 12mA |
| For measuring | AC/DC | AC/DC | AC/DC | AC/DC | AC/DC | AC/DC |
| Frequency | 120kHz | 120kHz | 120kHz | 120kHz | 120kHz | 120kHz |
| Linearity | ±1% | ±1% | ±1% | ±1% | ±1% | ±1% |
| Mounting type | Surface Mount, Wettable Flank | Surface Mount | Surface Mount | Surface Mount | Surface Mount | Surface Mount |
Shared specifications
- Number of channels
- 1
- Package
- Tape & Reel (TR) Cut Tape (CT)
- Response time
- 4µs
Request a quote on any Allegro MicroSystems ACS7 Series part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.
Frequently asked questions
- How do the Allegro MicroSystems Allegro MicroSystems ACS7 Series variants differ?
- Allegro MicroSystems ACS7 Series part numbers differ by accuracy, case, current - sensing and current - supply. Use the selection guide above to pick by accuracy.
- How many Allegro MicroSystems Allegro MicroSystems ACS7 Series part numbers are listed?
- 111 Allegro MicroSystems Allegro MicroSystems ACS7 Series part numbers are listed, each with specifications and a datasheet where available.
